- Maschinencode
- RO147
- Hersteller
- SCHIAVI
- Modello
- PATRIOT
- Baujahr
- 1995
- Number of colors
- 8
- Print possibilities
- 7+1, 8+0
- Drive
- Cardan
- Trolley system
- Yes
- Web width (mm)
- 1430
- Print width (mm)
- 1400
- Print repeat range (mm)
- 400-1000 mm
- Drying specifications
- units 1 to 7 , 1 blowing fan each unit , single drying hood 2, 5 mt , and one main exhaust fan ; for unt 8 double drying hood 2 x 2,,5 mt , 1 blowing and 1 exhaust . Automatic air recirculation unit with LEL control by Nira for all units
- Drying heat surce
- Thermo oil heaters
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- BST
- Register controll
- BOBST S 3100
- Vyscosity control
- 8 automatic Selectra
- Corona treatment
- yes by MERO
- Print cylinders
- 300
- Note
- 14 trolleys Fire protection system on all units
Maschinencode | RO147 |
Hersteller | SCHIAVI |
Modello | PATRIOT |
Baujahr | 1995 |
Number of colors | 8 |
Print possibilities | 7+1, 8+0 |
Drive | Cardan |
Trolley system | Yes |
Web width (mm) | 1430 |
Print width (mm) | 1400 |
Print repeat range (mm) | 400-1000 mm |
Drying specifications | units 1 to 7 , 1 blowing fan each unit , single drying hood 2, 5 mt , and one main exhaust fan ; for unt 8 double drying hood 2 x 2,,5 mt , 1 blowing and 1 exhaust . Automatic air recirculation unit with LEL control by Nira for all units |
Drying heat surce | Thermo oil heaters |
Unwinder type | Turret Automatic |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret Automatic |
Max reel diameter rewinder (mm) | 1000 |
Videocamera | BST |
Register controll | BOBST S 3100 |
Vyscosity control | 8 automatic Selectra |
Corona treatment | yes by MERO |
Print cylinders | 300 |
Note | 14 trolleys Fire protection system on all units |
