Paper sack making machines are made up from a tuber and a bottomer and are used to produce multilayer paper for industrial sacks. These are used for several applications from cement bags, to chemicals, food and seed packagings.
Ask more informations
- Machine Code
- SA27
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- AM 8115 CL AD 8320CL
- Year
- 2019
- Type
- Complete line
- Note
- - Tuber Tube Width: 26 cm - 60cm - Cut-off Length Flush Cut: 32cm - cm 105 - Cut-off length - Stepped End : 38 cm - 105cm - Reell width: 123 cm - Reel diameter: 130cm - Speed: 500 tubes/min - No. of plies : 3 - Remote Access Yes - Tear-off unit Belt system - No. of colors 4 - Pre-printed reels option: Yes W&H Bottomer AD8320 CL Year of construction 2019 - Sack Width: 28cm - 55cm - Sack Length Stepped end: 32cm - 74cm - Sack Length Flush Cut: 32cm - 74cm - Bottom Width - Stepped End: 8cm - 14cm - Bottom Width - Flush Cut: 8 cm- 14cm - Width of Opened Bottom: 16cm - 34cm - Bottom Centre Distance: 24 cm - 70cm - Tube Length: 40 cm - 94cm - Valve - Cut-off Length: 10cm - 25cm - Valve Ply : 2 plies valve - Bottom Patch - Cut off Length: 16 cm - 45cm
| Machine Code | SA27 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | AM 8115 CL AD 8320CL |
| Year | 2019 |
| Type | Complete line |
| Note | - Tuber Tube Width: 26 cm - 60cm - Cut-off Length Flush Cut: 32cm - cm 105 - Cut-off length - Stepped End : 38 cm - 105cm - Reell width: 123 cm - Reel diameter: 130cm - Speed: 500 tubes/min - No. of plies : 3 - Remote Access Yes - Tear-off unit Belt system - No. of colors 4 - Pre-printed reels option: Yes W&H Bottomer AD8320 CL Year of construction 2019 - Sack Width: 28cm - 55cm - Sack Length Stepped end: 32cm - 74cm - Sack Length Flush Cut: 32cm - 74cm - Bottom Width - Stepped End: 8cm - 14cm - Bottom Width - Flush Cut: 8 cm- 14cm - Width of Opened Bottom: 16cm - 34cm - Bottom Centre Distance: 24 cm - 70cm - Tube Length: 40 cm - 94cm - Valve - Cut-off Length: 10cm - 25cm - Valve Ply : 2 plies valve - Bottom Patch - Cut off Length: 16 cm - 45cm |
ROGNINI Tuber and printing section
-
Machine Code: SA30
-
Year: 1965
WINDMÖLLER & HÖLSCHER AM 8115CL AD 8300
-
Machine Code: SA26
-
Year: 2016
WINDMÖLLER & HÖLSCHER AM 8115 + AD8320 CL
-
Machine Code: SA31
-
Year: 2021
