Paper bag making machines fold a paper web into a square bottom SOS paper bag. These bags with block bottom may be produced in 1 or more layers of paper depending on machine's equipment and specifications. Some of these paper bag making machines are equipped to attach a handle on the bag, which may be: twisted handle or a flat handle.
Ask more informations
- Machine Code
- SO332
- Manufacturer
- CURIONI
- Modello
- SUN MASTER
- Year
- 1991
- Width (mm)
- 1430
- Feed:
- Reel fed
- Handel unit
- Twisted
- Bag length max (mm)
- 760
- Bag length min (mm)
- 400
- Bag width max (mm)
- 540
- Bag width min (mm)
- 270
- Bottom width max (mm)
- 80
- Bottom width (mm)
- 299
- Unwinder
- Single 1430mm wide
- Note
- For Square bottom Handle width : max 102mm Handle lenght (fixed) 155mm (1) ; 165mm (2) ; 175mm (3) Width handle flap max 203mm Height handle flap 50mm 1500mm diameter paper bag reel. 720mm-1430mm- width paper bag reel 1100mm diameter paper reel flap handle 100max width paper reel flap handle Workable paper weight 80-150 g/m2
| Machine Code | SO332 |
| Manufacturer | CURIONI |
| Modello | SUN MASTER |
| Year | 1991 |
| Width (mm) | 1430 |
| Feed: | Reel fed |
| Handel unit | Twisted |
| Bag length max (mm) | 760 |
| Bag length min (mm) | 400 |
| Bag width max (mm) | 540 |
| Bag width min (mm) | 270 |
| Bottom width max (mm) | 80 |
| Bottom width (mm) | 299 |
| Unwinder | Single 1430mm wide |
| Note | For Square bottom Handle width : max 102mm Handle lenght (fixed) 155mm (1) ; 165mm (2) ; 175mm (3) Width handle flap max 203mm Height handle flap 50mm 1500mm diameter paper bag reel. 720mm-1430mm- width paper bag reel 1100mm diameter paper reel flap handle 100max width paper reel flap handle Workable paper weight 80-150 g/m2 |
