Paper bag making machines fold a paper web into a square bottom SOS paper bag. These bags with block bottom may be produced in 1 or more layers of paper depending on machine's equipment and specifications. Some of these paper bag making machines are equipped to attach a handle on the bag, which may be: twisted handle or a flat handle.
Ask more informations
- Machine Code
- SO310
- Manufacturer
- Jiangsu nanjiang machinery co.ltd.
- Modello
- WFD-450
- Year
- 2017
- Width (mm)
- 450
- Materials
- Paper
- Feed:
- Reel fed
- Handel unit
- Twisted
- Bag length max (mm)
- 490
- Bag length min (mm)
- 240
- Bag width max (mm)
- 450
- Bag width min (mm)
- 220
- Bottom width max (mm)
- 190
- Bottom width (mm)
- 80
- Cycle / min
- 40-70
- Note
- Paper Bag Width : 220-450 mm Paper Tube Length : 240-490 mm Bag Bottom Width : 80-190 mm Bag Top fold Depth : 45 mm-60 mm Type of Glue : Cold & Hotmelt Glue Speed : 40-70 Bags/min Total Power : 28 kw
| Machine Code | SO310 |
| Manufacturer | Jiangsu nanjiang machinery co.ltd. |
| Modello | WFD-450 |
| Year | 2017 |
| Width (mm) | 450 |
| Materials | Paper |
| Feed: | Reel fed |
| Handel unit | Twisted |
| Bag length max (mm) | 490 |
| Bag length min (mm) | 240 |
| Bag width max (mm) | 450 |
| Bag width min (mm) | 220 |
| Bottom width max (mm) | 190 |
| Bottom width (mm) | 80 |
| Cycle / min | 40-70 |
| Note | Paper Bag Width : 220-450 mm Paper Tube Length : 240-490 mm Bag Bottom Width : 80-190 mm Bag Top fold Depth : 45 mm-60 mm Type of Glue : Cold & Hotmelt Glue Speed : 40-70 Bags/min Total Power : 28 kw |
