Cast film extrusion lines are commonly used to extrude plastic films especially for flexible packaging industry. / In a cast film extruder PE, PP or PA granulates (or other polymers) are melted inro an extruder and pushed through a flat extrusion die (T die), extruding a sheet of molten polymer onto a cooled roller (chill roll).
Ask more informations
- Machine Code
- CA168
- Manufacturer
- TECHNO COATING ENGINEERING
- Year
- 1999
- Number of layers
- 5
- Film structure
- A/C/B/C/D
- Material
- Stretch film LLDPE
- Film width (mm)
- 3000
- Speed (m/min)
- 450 mt/min - (max 600 mt/min)
- Output (Kg/h)
- 1650 and 1700 Kg/h
- Head description
- EDI
- Die width (mm)
- 3700 mm
- Chill roll unit
- 2 cylinders of diam 980 mm and diam 450 mm
- Thickness controll system
- Yes
- Web guide
- Yes
- Rewinder max reel diameter (mm)
- 600
- Rewinder description
- Dual 1500mm each.
- Note
- PLC - SIEMENS S7/400 Power - 2800 Kw
| Machine Code | CA168 |
| Manufacturer | TECHNO COATING ENGINEERING |
| Year | 1999 |
| Number of layers | 5 |
| Film structure | A/C/B/C/D |
| Material | Stretch film LLDPE |
| Film width (mm) | 3000 |
| Speed (m/min) | 450 mt/min - (max 600 mt/min) |
| Output (Kg/h) | 1650 and 1700 Kg/h |
| Head description | EDI |
| Die width (mm) | 3700 mm |
| Chill roll unit | 2 cylinders of diam 980 mm and diam 450 mm |
| Thickness controll system | Yes |
| Web guide | Yes |
| Rewinder max reel diameter (mm) | 600 |
| Rewinder description | Dual 1500mm each. |
| Note | PLC - SIEMENS S7/400 Power - 2800 Kw |
