Gravure presses are used to print on different supports: plastic films, paper and aluminium foil.
Ask more informations
- Machine Code
- RO129
- Manufacturer
- CERUTTI
- Modello
- 960
- Year
- 1996
- Number of colors
- 10
- Print possibilities
- 9+0, 8+1, 9+ lamination
- Overhaul/renovation
- 2010 new digital drives by SIEMENS , New PLC Siemens S7 , new register control , new motors and drives on infeed and outfeed driven calender nips, new machine computer, new Video camera
- Drive
- Cardan
- Trolley system
- Yes
- Web width (mm)
- 1220
- Print width (mm)
- 1200
- Print repeat range (mm)
- 400-900 mm
- Drying specifications
- Unit 1 single extended ; stations 2-7 single standard hood; station 8 reversible two zones double hood, station 9 reversible two zones double hood extended 2x 3 mt ;station 10 two zone super extended 2x 5 mt ; thermo oil heaters, automatic recirculation system with LEL control by NIRA
- Drying heat surce
- Thermo oil heaters
- Unwinder type
- Turret automatic diam 900 mm
- Max reel diameter unwinder (mm)
- 900
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 900
- Videocamera
- Eltromat 3 ccd with monitor 42"
- Register controll
- GRAFYKONTROL CR 33 LT new 2010
- Vyscosity control
- SELECTRA new
- Corona treatment
- YES double side for secondary unwinder
- Print cylinders
- 500
- Note
- 14 trolleys ESA systems by ACE on units 2 - 9
| Machine Code | RO129 |
| Manufacturer | CERUTTI |
| Modello | 960 |
| Year | 1996 |
| Number of colors | 10 |
| Print possibilities | 9+0, 8+1, 9+ lamination |
| Overhaul/renovation | 2010 new digital drives by SIEMENS , New PLC Siemens S7 , new register control , new motors and drives on infeed and outfeed driven calender nips, new machine computer, new Video camera |
| Drive | Cardan |
| Trolley system | Yes |
| Web width (mm) | 1220 |
| Print width (mm) | 1200 |
| Print repeat range (mm) | 400-900 mm |
| Drying specifications | Unit 1 single extended ; stations 2-7 single standard hood; station 8 reversible two zones double hood, station 9 reversible two zones double hood extended 2x 3 mt ;station 10 two zone super extended 2x 5 mt ; thermo oil heaters, automatic recirculation system with LEL control by NIRA |
| Drying heat surce | Thermo oil heaters |
| Unwinder type | Turret automatic diam 900 mm |
| Max reel diameter unwinder (mm) | 900 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 900 |
| Videocamera | Eltromat 3 ccd with monitor 42" |
| Register controll | GRAFYKONTROL CR 33 LT new 2010 |
| Vyscosity control | SELECTRA new |
| Corona treatment | YES double side for secondary unwinder |
| Print cylinders | 500 |
| Note | 14 trolleys ESA systems by ACE on units 2 - 9 |
