Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1159
- Manufacturer
- COMEXI
- Modello
- FP 2210 GL
- Year
- 2002
- Number of colors
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 680
- Unwinder type
- Double turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Double turret automatica
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 gas burners, 2 zones with independent ventilation
- Videocamera
- AVT Print Vision 9000 NT
- Web guides
- Yes, BST
- Vyscosity control
- Yes
- Inking system
- Closed chamber doctor blades
- Print Sleeves
- 355x8, 365x9, 380x28, 390x10, 395x9, 400x8, 405x16, 410x10, 415x20, 420x8, 430x8, 440x10, 445x10, 450x8, 455x10, 470x9, 475x10, 480x8, 500x16, 515x9, 535x9, 545x10, 555x9, 560x10, 565x10, 575x20, 580x10, 590x8, 605x10, 615x8, 635x8, 645x8, 655x8, 675x8, other 14
- Note
- The color 7 needs a reparation
| Machine Code | FL1159 |
| Manufacturer | COMEXI |
| Modello | FP 2210 GL |
| Year | 2002 |
| Number of colors | 10 |
| Print possibilityes | 10+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 680 |
| Unwinder type | Double turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Double turret automatica |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 gas burners, 2 zones with independent ventilation |
| Videocamera | AVT Print Vision 9000 NT |
| Web guides | Yes, BST |
| Vyscosity control | Yes |
| Inking system | Closed chamber doctor blades |
| Print Sleeves | 355x8, 365x9, 380x28, 390x10, 395x9, 400x8, 405x16, 410x10, 415x20, 420x8, 430x8, 440x10, 445x10, 450x8, 455x10, 470x9, 475x10, 480x8, 500x16, 515x9, 535x9, 545x10, 555x9, 560x10, 565x10, 575x20, 580x10, 590x8, 605x10, 615x8, 635x8, 645x8, 655x8, 675x8, other 14 |
| Note | The color 7 needs a reparation |
