Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1127
- Manufacturer
- FLEXOTECNICA
- Modello
- TACHYS
- Year
- 1998
- Number of colors
- 9
- Print possibilityes
- 8+1
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 820
- Min print repeat (mm)
- 280
- Max print repeat (mm)
- 700
- Unwinder type
- double bracket unwinder with dancing roller tension control
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones for CI + 1 zone for downstream stack unit , 4 fans , tunnel 3 mt long
- Videocamera
- yes
- Corona treatment
- yes
- Web guides
- yes
- Washing system
- no
- Inking system
- Closed chamber doctor blades
- Print Sleeves
- 25 sets of 8 print sleeves for each following repeat 300, 310, 320, 330, 340 , 350 , 360 , 370 , 380 , 390 , 400 410 , 420 , 430 , 440 , 450 , , 470 480 , 490 , 500 , 520 ,530 , 540 , 550 , 560 , 580
- Note
- Register control between Ci and stack down stream section Option Plate Mounter
| Machine Code | FL1127 |
| Manufacturer | FLEXOTECNICA |
| Modello | TACHYS |
| Year | 1998 |
| Number of colors | 9 |
| Print possibilityes | 8+1 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Web width (mm) | 850 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 280 |
| Max print repeat (mm) | 700 |
| Unwinder type | double bracket unwinder with dancing roller tension control |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones for CI + 1 zone for downstream stack unit , 4 fans , tunnel 3 mt long |
| Videocamera | yes |
| Corona treatment | yes |
| Web guides | yes |
| Washing system | no |
| Inking system | Closed chamber doctor blades |
| Print Sleeves | 25 sets of 8 print sleeves for each following repeat 300, 310, 320, 330, 340 , 350 , 360 , 370 , 380 , 390 , 400 410 , 420 , 430 , 440 , 450 , , 470 480 , 490 , 500 , 520 ,530 , 540 , 550 , 560 , 580 |
| Note | Register control between Ci and stack down stream section Option Plate Mounter |
UTECO ONYX 808
-
Machine Code: FL1108
-
Year: 2011
-
Web width (mm): 1150
COMEXI FB 2108 CNC GL
-
Machine Code: FL0806
-
Year: 2003
-
Web width (mm): 1270
FISCHER & KRECKE 16S
-
Machine Code: FL1087
-
Year: 2005
-
Web width (mm): 1100
TCM Midi 50 - 114
-
Machine Code: FL0965
-
Year: 1998
-
Web width (mm): 1350
COMEXI FW1508
-
Machine Code: FL1125
-
Year: 2006
-
Web width (mm): 1270
FISCHER & KRECKE F16 S
-
