- Code Machine
- FL1127
- Fabricant
- FLEXOTECNICA
- Modello
- TACHYS
- Année
- 1998
- Number of colors
- 9
- Print possibilityes
- 8+1
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 820
- Min print repeat (mm)
- 280
- Max print repeat (mm)
- 700
- Unwinder type
- double bracket unwinder with dancing roller tension control
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones for CI + 1 zone for downstream stack unit , 4 fans , tunnel 3 mt long
- Videocamera
- yes
- Corona treatment
- yes
- Web guides
- yes
- Washing system
- no
- Inking system
- Closed chamber doctor blades
- Print Sleeves
- 25 sets of 8 print sleeves for each following repeat 300, 310, 320, 330, 340 , 350 , 360 , 370 , 380 , 390 , 400 410 , 420 , 430 , 440 , 450 , , 470 480 , 490 , 500 , 520 ,530 , 540 , 550 , 560 , 580
- Note
- Register control between Ci and stack down stream section Option Plate Mounter
| Code Machine | FL1127 |
| Fabricant | FLEXOTECNICA |
| Modello | TACHYS |
| Année | 1998 |
| Number of colors | 9 |
| Print possibilityes | 8+1 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Web width (mm) | 850 |
| Print width (mm) | 820 |
| Min print repeat (mm) | 280 |
| Max print repeat (mm) | 700 |
| Unwinder type | double bracket unwinder with dancing roller tension control |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones for CI + 1 zone for downstream stack unit , 4 fans , tunnel 3 mt long |
| Videocamera | yes |
| Corona treatment | yes |
| Web guides | yes |
| Washing system | no |
| Inking system | Closed chamber doctor blades |
| Print Sleeves | 25 sets of 8 print sleeves for each following repeat 300, 310, 320, 330, 340 , 350 , 360 , 370 , 380 , 390 , 400 410 , 420 , 430 , 440 , 450 , , 470 480 , 490 , 500 , 520 ,530 , 540 , 550 , 560 , 580 |
| Note | Register control between Ci and stack down stream section Option Plate Mounter |
