Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
- Machine Code
- FL0995
- Manufacturer
- FLEXOTECNICA
- Modello
- TACHYS
- Year
- 2000
- Number of colors
- 8
- Print possibilityes
- PE-OPP-PAPER
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 950
- Print width (mm)
- 900
- Min print repeat (mm)
- 310
- Max print repeat (mm)
- 700
- Unwinder type
- TURRET
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- TURRET
- Max reel diameter rewinder (mm)
- 1000
- Drying
- ELECTRIC
- Videocamera
- RGB
- Web guides
- BST
- Vyscosity control
- YES
- Inking system
- 8X PNEUMATIC PUMPS
- Anilox
- 7 X 370; 3 X 220; 3 X 80; 1 X 140 ; 2 X 100; 1 X 180; 1 X 250; 1 X 150
- Print Sleeves
- 8 X (310, 320, 330, 340, 350, 360, 370, 390) 8 X (400, 410, 420, 430, 440, 450, 460, 480) 16 X (500) 8 X (510, 520, 540, 550, 560) 8 X (570, 580, 600, 620, 640, 660, 680)
- Print cylinders
- 4 X 76 / 4 X 152 / PNEUMATICI
- Note
- Mechanical speed 400/min
| Machine Code | FL0995 |
| Manufacturer | FLEXOTECNICA |
| Modello | TACHYS |
| Year | 2000 |
| Number of colors | 8 |
| Print possibilityes | PE-OPP-PAPER |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | No |
| Computer supervision | Yes |
| Web width (mm) | 950 |
| Print width (mm) | 900 |
| Min print repeat (mm) | 310 |
| Max print repeat (mm) | 700 |
| Unwinder type | TURRET |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | TURRET |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | ELECTRIC |
| Videocamera | RGB |
| Web guides | BST |
| Vyscosity control | YES |
| Inking system | 8X PNEUMATIC PUMPS |
| Anilox | 7 X 370; 3 X 220; 3 X 80; 1 X 140 ; 2 X 100; 1 X 180; 1 X 250; 1 X 150 |
| Print Sleeves | 8 X (310, 320, 330, 340, 350, 360, 370, 390) 8 X (400, 410, 420, 430, 440, 450, 460, 480) 16 X (500) 8 X (510, 520, 540, 550, 560) 8 X (570, 580, 600, 620, 640, 660, 680) |
| Print cylinders | 4 X 76 / 4 X 152 / PNEUMATICI |
| Note | Mechanical speed 400/min |
