- Maschinencode
- SA14
- Hersteller
- WINDMÖLLER & HÖLSCHER
- Modello
- AEK 1140
- Baujahr
- 1980
- Overhaul/renovation
- reconditioned 2013.: mechanical and electrical completely overhauled, sandblasting, painting, replacing of all bearings.
- Typ
- Tuber
- Note
- - flush cut - 3 layers/roll stand - tube widths: 30-60 cm - Tube with guset - tube lengths: 60-130 cm ( *possible less with photocell unit) - 4 colours in line printer with only 4 cylinders and following gears - format gears: 62,64,70,74,80,85,89,90,94,96,98,100,101,105,108,110,114,115,116,120 cm, cliche thiknes 2,84 mm mechanical and electrical completely overhauled, sandblasting, painting, replacing of all bearings. visible in production, mechanical speed is 200 pieces / min. and machine has been tested up to 120 - 150 pieces / min. depending on the size of the bags, experience of operators etc. etc.. - 3 Web guide
| Maschinencode | SA14 |
| Hersteller | WINDMÖLLER & HÖLSCHER |
| Modello | AEK 1140 |
| Baujahr | 1980 |
| Overhaul/renovation | reconditioned 2013.: mechanical and electrical completely overhauled, sandblasting, painting, replacing of all bearings. |
| Typ | Tuber |
| Note | - flush cut - 3 layers/roll stand - tube widths: 30-60 cm - Tube with guset - tube lengths: 60-130 cm ( *possible less with photocell unit) - 4 colours in line printer with only 4 cylinders and following gears - format gears: 62,64,70,74,80,85,89,90,94,96,98,100,101,105,108,110,114,115,116,120 cm, cliche thiknes 2,84 mm mechanical and electrical completely overhauled, sandblasting, painting, replacing of all bearings. visible in production, mechanical speed is 200 pieces / min. and machine has been tested up to 120 - 150 pieces / min. depending on the size of the bags, experience of operators etc. etc.. - 3 Web guide |
