MILLTEX Querschneider // Sheeters // Converting machines // Gebrauchte Maschinen // Tecno Converting 2000 S.r.l.

Fotogalerie

Maschinencode: SS52
Hersteller: MILLTEX
Baujahr: 2002
Width (mm): 1600
Materials: plastic sheet paper and board
Note: Pair of feeding cylinders, tension regulation through load cells, cutting equipment composed of fixed lower knife and rotating upper knife, transport unit composed of tow rollers and flat belts. Stacking on pantograph, which is continuously lowered, keeping the stacking level constant. Intermediate stacking equipment when changing pallets. Evacuation equipment for collecting waste in a box. Sheets: height 1.030-1.300 mm, length 850-1.580 mm, thickness 140 - 1.000 micron

Maschinencode	SS52
Hersteller	MILLTEX
Baujahr	2002
Width (mm)	1600
Materials	plastic sheet paper and board
Note	Pair of feeding cylinders, tension regulation through load cells, cutting equipment composed of fixed lower knife and rotating upper knife, transport unit composed of tow rollers and flat belts. Stacking on pantograph, which is continuously lowered, keeping the stacking level constant. Intermediate stacking equipment when changing pallets. Evacuation equipment for collecting waste in a box. Sheets: height 1.030-1.300 mm, length 850-1.580 mm, thickness 140 - 1.000 micron
