- Maschinencode
- LA490
- Hersteller
- GENERAL CONVERTING MACHINES
- Baujahr
- 2014
- Application
- Duplex lamination
- Type of lamination/coating
- SOLVENTLESS
- Overhaul/renovation
- New PLC SIEMENS and touch screen HMI panel. Teleservice with remote access.
- Working width (mm)
- 1400
- Speed
- 400 m/min
- First unwinder type
- Shfatless
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Shaftless
- Max diameter reel unwinder
- 1000
- Rewinder type
- Shaftless
- Max diameter reel rewinder
- 1000
- Coating unit
- 5 rollers staggered for solventless. Sleeve type transfer sleeve
- pumping mixing unit
- 2 component mixer
- Coating rollers
- 5 transfer sleeves new (to be prepared at width required by customer
- Note
- Tension control through dancing rollers
| Maschinencode | LA490 |
| Hersteller | GENERAL CONVERTING MACHINES |
| Baujahr | 2014 |
| Application | Duplex lamination |
| Type of lamination/coating | SOLVENTLESS |
| Overhaul/renovation | New PLC SIEMENS and touch screen HMI panel. Teleservice with remote access. |
| Working width (mm) | 1400 |
| Speed | 400 m/min |
| First unwinder type | Shfatless |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Shaftless |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Shaftless |
| Max diameter reel rewinder | 1000 |
| Coating unit | 5 rollers staggered for solventless. Sleeve type transfer sleeve |
| pumping mixing unit | 2 component mixer |
| Coating rollers | 5 transfer sleeves new (to be prepared at width required by customer |
| Note | Tension control through dancing rollers |
