DAVIS STANDARD - ERWEPA Extrusion lamination // Extrusion lamination // Converting machines // Gebrauchte Maschinen // Tecno Converting 2000 S.r.l.

** SOLD **

Fotogalerie

Maschinencode: EC46
Hersteller: DAVIS STANDARD - ERWEPA
Baujahr: 2012
Width (mm): 1350
Coating/lamination units: 1 with coextrusion
Coating/lamination unit 1 description: T die + chill roll
Treatment: 1 corona + Primer coating station with drying
Primary unwinder description: Turret shafted max diameter 1000mm bidirectional. Max weight 1,5 tons
Secondary unwinder description: Turret shafted max diameter 1000mm bidirectional.
Rewinder description: Turret shafted bidirectional max diameter 1000mm
Speed: 300 m/min
Product structure / Materials: Paper:20 - 150 g/m2 Aluminium :6,35 - 25 µm PE:40 -120 µm BOPA: 15-50 µm BOPET: 9 -50 µm (smooth and metallised) BOPP: 15- 50 µm (smooth and metallised) Nonwoven PP: optional
Note: Typlcal substrates: Paper:20 - 150 g/m2 Aluminium :6,35 - 25 µm PE:40 -120 µm BOPA: 15-50 µm BOPET: 9 -50 µm (smooth and metallised) BOPP: 15- 50 µm (smooth and metallised) Nonwoven PP: optional Edge Trim Razor Blade Beta Thickness Gauge PROTAGON Edge Trim Shear Cut Centre Slit&Spreader Roller 3 extruders

Maschinencode	EC46
Hersteller	DAVIS STANDARD - ERWEPA
Baujahr	2012
Width (mm)	1350
Coating/lamination units	1 with coextrusion
Coating/lamination unit 1 description	T die + chill roll
Treatment	1 corona + Primer coating station with drying
Primary unwinder description	Turret shafted max diameter 1000mm bidirectional. Max weight 1,5 tons
Secondary unwinder description	Turret shafted max diameter 1000mm bidirectional.
Rewinder description	Turret shafted bidirectional max diameter 1000mm
Speed	300 m/min
Product structure / Materials	Paper:20 - 150 g/m2 Aluminium :6,35 - 25 µm PE:40 -120 µm BOPA: 15-50 µm BOPET: 9 -50 µm (smooth and metallised) BOPP: 15- 50 µm (smooth and metallised) Nonwoven PP: optional
Note	Typlcal substrates: Paper:20 - 150 g/m2 Aluminium :6,35 - 25 µm PE:40 -120 µm BOPA: 15-50 µm BOPET: 9 -50 µm (smooth and metallised) BOPP: 15- 50 µm (smooth and metallised) Nonwoven PP: optional Edge Trim Razor Blade Beta Thickness Gauge PROTAGON Edge Trim Shear Cut Centre Slit&Spreader Roller 3 extruders
