- Codice Macchina
- EX616
- Manufacturer
- BANDERA
- Modello
- TECHNOFLEX
- Year
- 2015
- Numero di strati
- 3
- Struttura film
- ABC
- Materiali
- STRETCH ,LLDPE, LDPE, EVA, mLLDPE
- Larghezza film
- 1700
- Output (Kg/h)
- Max production: Stretch hood with 280 mm die plate: 450 kg/h ;Shrink or lamination film with 400 mm die plate: 600 kg/h
- Rif strati estrusore 1:
- A
- Screw diam 1
- 60MM
- Description 1
- 30D ,3 gravimetric batch dosing units 4 components
- Rif strati estrusore 2:
- B
- Screw diam 2
- 100MM
- Description 2
- 30D ,3 gravimetric batch dosing units 4 components
- Rif strati estrusore 3:
- C
- Screw diam 3
- 60MM
- Description 3
- 30D ,3 gravimetric batch dosing units 4 components
- Descrizione testa
- IBC ,,Air Ring Karat 3 Com with high adjustment
- Diamtero filiera (mm)
- 280 and 400 mm
- Controllo di spessore
- Automatic thickness control system Kundig
- Panel for gussets
- Gusseting
- Stiro
- Rotating haul off with gusseting device
- Trattamento Corona
- Corona treatment Cason for both sides
- Guida film
- Web guide 1800 mm
- Descrizione avvolgitore
- Double automatic rewinder TW 1800
- Ulteriori informazioni
- Line to produce stretch hood, lamination film and shrink film Manual screen changers Motorized calibration basket Automatic core loading system SAFE LOAD Antistatic bars Chiller ABF Tower Thickness 20-200 my
| Codice Macchina | EX616 |
| Manufacturer | BANDERA |
| Modello | TECHNOFLEX |
| Year | 2015 |
| Numero di strati | 3 |
| Struttura film | ABC |
| Materiali | STRETCH ,LLDPE, LDPE, EVA, mLLDPE |
| Larghezza film | 1700 |
| Output (Kg/h) | Max production: Stretch hood with 280 mm die plate: 450 kg/h ;Shrink or lamination film with 400 mm die plate: 600 kg/h |
| Rif strati estrusore 1: | A |
| Screw diam 1 | 60MM |
| Description 1 | 30D ,3 gravimetric batch dosing units 4 components |
| Rif strati estrusore 2: | B |
| Screw diam 2 | 100MM |
| Description 2 | 30D ,3 gravimetric batch dosing units 4 components |
| Rif strati estrusore 3: | C |
| Screw diam 3 | 60MM |
| Description 3 | 30D ,3 gravimetric batch dosing units 4 components |
| Descrizione testa | IBC ,,Air Ring Karat 3 Com with high adjustment |
| Diamtero filiera (mm) | 280 and 400 mm |
| Controllo di spessore | Automatic thickness control system Kundig |
| Panel for gussets | Gusseting |
| Stiro | Rotating haul off with gusseting device |
| Trattamento Corona | Corona treatment Cason for both sides |
| Guida film | Web guide 1800 mm |
| Descrizione avvolgitore | Double automatic rewinder TW 1800 |
| Ulteriori informazioni | Line to produce stretch hood, lamination film and shrink film Manual screen changers Motorized calibration basket Automatic core loading system SAFE LOAD Antistatic bars Chiller ABF Tower Thickness 20-200 my |
