- Codice Macchina
- RO150
- Manufacturer
- DCM
- Modello
- ATENA
- Year
- 2007
- Numero di colori
- 7
- Motorizzazione
- Electronic shaft
- Trolley system
- Yes
- Larghezza nastro (mm)
- 660
- Larghezza stampa (mm)
- 640
- Formato stampa (mm)
- 360-760 mm
- Drying specifications
- The low temperature high efficiency dryer insure an air circulation and heating. The circulating air in the dryer has a velocity of 40 m/s with an adjustable fan and blower 7000 m3/hour and heated by thermo-oil installation and with temperature regulation. Very precisely controlled air recirculation allows an efficient dryer at a low temperature, saving thus energy and substrate quality
- Drying heat surce
- thermo-oil instalation
- Unwinder type
- Automatic
- Diametro massimo svolgitore (mm)
- 1800
- Rewinder type
- Single Shaft
- Max reel diameter rewinder (mm)
- 1300
- Videocamera
- BST Handyscan
- Controllo di registro
- DGC 650 from Eltromat
- Vyscosity control
- Viscosity control equipment with solvent reservoir enables to measure and adjust viscosity of solvent inks (Opticolor Junior)
- Cilindri stampa
- 67 printing cylinders (13 steel base only and 54 copper covered) ;3 sets of cutting + creasing tools
- Ulteriori informazioni
- SUBSTRATE: PAPER/CARDBOARD SUBSTRATE WEIGHT: 60-300 gsm Production of cigaretes packaging, paper labels and cardboard packaging Register control DGC 650 from Eltromat Splicing device AIR VOLUME : 7000 m3/h AIR VELOCITY : 40 m/s MAXIMUM REEL DIAMETER 1800 mm MAXIMUM WEB WIDTH 660 mm MAXIMUM PRINTING WIDTH 640 mm MAXIMUM PRINTING REPEAT 760 mm MINIMUM PRINTING REPEAT 360 mm MAXIMUM ROTARY DIE CUTTING WIDTH 660 mm MAXIMUM ROTARY DIE CUTTING REPEAT 800 mm MINIMUM ROTARY DIE CUTTING REPEAT 535 mm ELECTRICAL SPECIFICATIONS 400 V, 3 phases, 50 Hz PRODUCTION SPEED up to 200 m/min 3 stage rotary die cutting unit RDC10 in-line – embossing, creasing and cutting/stripping cassettes Production: roll to roll, roll to sheet, roll to die-cut product Drying: thermo-oil installation Register control: DGC 650 from Eltromat REGISTER ACCURACY PRINT TO PRINT : +/- 0.10 mm PRINT TO CUT : +/- 0.15 mm Additional equipment included in price – 67 printing cylinders (13 steel base only and 54 copper covered) – 3 sets of cutting + creasing tools (buyer can’t use the whole tool, only original ATN cassettes in which the tools are packed)
| Codice Macchina | RO150 |
| Manufacturer | DCM |
| Modello | ATENA |
| Year | 2007 |
| Numero di colori | 7 |
| Motorizzazione | Electronic shaft |
| Trolley system | Yes |
| Larghezza nastro (mm) | 660 |
| Larghezza stampa (mm) | 640 |
| Formato stampa (mm) | 360-760 mm |
| Drying specifications | The low temperature high efficiency dryer insure an air circulation and heating. The circulating air in the dryer has a velocity of 40 m/s with an adjustable fan and blower 7000 m3/hour and heated by thermo-oil installation and with temperature regulation. Very precisely controlled air recirculation allows an efficient dryer at a low temperature, saving thus energy and substrate quality |
| Drying heat surce | thermo-oil instalation |
| Unwinder type | Automatic |
| Diametro massimo svolgitore (mm) | 1800 |
| Rewinder type | Single Shaft |
| Max reel diameter rewinder (mm) | 1300 |
| Videocamera | BST Handyscan |
| Controllo di registro | DGC 650 from Eltromat |
| Vyscosity control | Viscosity control equipment with solvent reservoir enables to measure and adjust viscosity of solvent inks (Opticolor Junior) |
| Cilindri stampa | 67 printing cylinders (13 steel base only and 54 copper covered) ;3 sets of cutting + creasing tools |
| Ulteriori informazioni | SUBSTRATE: PAPER/CARDBOARD SUBSTRATE WEIGHT: 60-300 gsm Production of cigaretes packaging, paper labels and cardboard packaging Register control DGC 650 from Eltromat Splicing device AIR VOLUME : 7000 m3/h AIR VELOCITY : 40 m/s MAXIMUM REEL DIAMETER 1800 mm MAXIMUM WEB WIDTH 660 mm MAXIMUM PRINTING WIDTH 640 mm MAXIMUM PRINTING REPEAT 760 mm MINIMUM PRINTING REPEAT 360 mm MAXIMUM ROTARY DIE CUTTING WIDTH 660 mm MAXIMUM ROTARY DIE CUTTING REPEAT 800 mm MINIMUM ROTARY DIE CUTTING REPEAT 535 mm ELECTRICAL SPECIFICATIONS 400 V, 3 phases, 50 Hz PRODUCTION SPEED up to 200 m/min 3 stage rotary die cutting unit RDC10 in-line – embossing, creasing and cutting/stripping cassettes Production: roll to roll, roll to sheet, roll to die-cut product Drying: thermo-oil installation Register control: DGC 650 from Eltromat REGISTER ACCURACY PRINT TO PRINT : +/- 0.10 mm PRINT TO CUT : +/- 0.15 mm Additional equipment included in price – 67 printing cylinders (13 steel base only and 54 copper covered) – 3 sets of cutting + creasing tools (buyer can’t use the whole tool, only original ATN cassettes in which the tools are packed) |
