- Code Machine
- SS80
- Fabricant
- STRACHAN & HENSHAW
- Année
- 1985
- Taper
- Synchro
- Width (mm)
- 1300
- Sheet length
- 500-1550mm
- Cycle / min
- max 400 cuts/min. max linear speed 300m/min. Actual operating speed depends on sheet length and material
- Max diameter reel unwinder
- 1800mm
- Note
- Paper and board up to 500 gsm 3 in line longitudinal slitters Min web width 300mm Unwinder cores: 152,302,305 mm Norman electronics length control unit
| Code Machine | SS80 |
| Fabricant | STRACHAN & HENSHAW |
| Année | 1985 |
| Taper | Synchro |
| Width (mm) | 1300 |
| Sheet length | 500-1550mm |
| Cycle / min | max 400 cuts/min. max linear speed 300m/min. Actual operating speed depends on sheet length and material |
| Max diameter reel unwinder | 1800mm |
| Note | Paper and board up to 500 gsm 3 in line longitudinal slitters Min web width 300mm Unwinder cores: 152,302,305 mm Norman electronics length control unit |
