- Code Machine
- BO68
- Fabricant
- DMT
- Modello
- TDO unit for PVC shrink labels
- Année
- 2004
- Material
- PVC for shrink labels
- Width (mm)
- 2500
- TDO description
- Inlet with 450-1000 mm, outlet after stretching 1600 - 2800 mm width; final width after trimming 2500 mm; stretching ratio 1:2 - 1:5; chain type heavy duty lubrificated 60 mm pitch; clips 120 mm pitch; feed zone 1,5 m, pre-heating 2 x3 m, stretching 2 x 3 m, neutral 1 x1 m, cooling/annhealing 6 x 2 m outlet 1 x 1.5 m. 5 independent fans, number of centract joins 5, temperature 60/200 C
- Pull roll unit
- Yes with trimming
- Rewinder width
- 2500 mm
- Rewinder description
- Turret automatic rewinder
- Note
- Composed of: unwinder TDO unit Turret automatic unwinder
Code Machine | BO68 |
Fabricant | DMT |
Modello | TDO unit for PVC shrink labels |
Année | 2004 |
Material | PVC for shrink labels |
Width (mm) | 2500 |
TDO description | Inlet with 450-1000 mm, outlet after stretching 1600 - 2800 mm width; final width after trimming 2500 mm; stretching ratio 1:2 - 1:5; chain type heavy duty lubrificated 60 mm pitch; clips 120 mm pitch; feed zone 1,5 m, pre-heating 2 x3 m, stretching 2 x 3 m, neutral 1 x1 m, cooling/annhealing 6 x 2 m outlet 1 x 1.5 m. 5 independent fans, number of centract joins 5, temperature 60/200 C |
Pull roll unit | Yes with trimming |
Rewinder width | 2500 mm |
Rewinder description | Turret automatic rewinder |
Note | Composed of: unwinder TDO unit Turret automatic unwinder |
BRUCKNER - DORNIER
-
Code Machine: BO80
-
Année: 1994
-
Width (mm): 8400
BRUCKNER
-
Code Machine: BO57
-
Année: 1990
-
Width (mm): 7400
MITSUBISHI
-
Code Machine: BO83
-
Année: 1998
-
Width (mm): 4200
DMT BOPP
-
Code Machine: BO67
-
Année: 1997
-
Width (mm): 6500
BRUCKNER
-
Code Machine: BO77
-
Année: 1999
-
Width (mm): 6600
BRUCKNER
-
Code Machine: BO90
-
Année: 2014
-
Width (mm): 8300
