- Code Machine
- FL1014
- Fabricant
- COMEXI
- Modello
- FB
- Année
- 2003
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1200
- Print width (mm)
- 1240
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic non stop
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic non stop
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans - Final tunnel 4.5 mt , thermo oil heat exchangers ,
- Videocamera
- YES by AVT Jupiter with defekt control
- Web guides
- Yes in and out
- Vyscosity control
- Yes automatic INELME
- Washing system
- Yes automatic Enviroxi
- Inking system
- Closed chamber doctor blades tot. 12
- Note
- In line slitting at rewinder
| Code Machine | FL1014 |
| Fabricant | COMEXI |
| Modello | FB |
| Année | 2003 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1200 |
| Print width (mm) | 1240 |
| Min print repeat (mm) | 400 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic non stop |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic non stop |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones 4 fans - Final tunnel 4.5 mt , thermo oil heat exchangers , |
| Videocamera | YES by AVT Jupiter with defekt control |
| Web guides | Yes in and out |
| Vyscosity control | Yes automatic INELME |
| Washing system | Yes automatic Enviroxi |
| Inking system | Closed chamber doctor blades tot. 12 |
| Note | In line slitting at rewinder |
