- Code Machine
- FL0864
- Fabricant
- UTECO
- Modello
- DIAMOND HP 108
- Année
- 2011
- Number of colors
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1550
- Print width (mm)
- 1500
- Min print repeat (mm)
- 420
- Max print repeat (mm)
- 870
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers
- Videocamera
- YEAS GRAFYKONTROL WITH 100 % INSPECTION SYSTEM
- Web guides
- yes BST in and out
- Vyscosity control
- yes automatic
- Washing system
- yes automatic
- Inking system
- closed chamber doctor blades ( 10+2 spares )
- Anilox
- 16 ceramic anilox sleeves
- Print Sleeves
- 60 + 10 carriers
- Note
- Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device Floorplan of the machine Width m. 7.60 Length m. 7.00pm Height m. 5.50
| Code Machine | FL0864 |
| Fabricant | UTECO |
| Modello | DIAMOND HP 108 |
| Année | 2011 |
| Number of colors | 10 |
| Print possibilityes | 10+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1550 |
| Print width (mm) | 1500 |
| Min print repeat (mm) | 420 |
| Max print repeat (mm) | 870 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers |
| Videocamera | YEAS GRAFYKONTROL WITH 100 % INSPECTION SYSTEM |
| Web guides | yes BST in and out |
| Vyscosity control | yes automatic |
| Washing system | yes automatic |
| Inking system | closed chamber doctor blades ( 10+2 spares ) |
| Anilox | 16 ceramic anilox sleeves |
| Print Sleeves | 60 + 10 carriers |
| Note | Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device Floorplan of the machine Width m. 7.60 Length m. 7.00pm Height m. 5.50 |
