- Code Machine
- FL738
- Fabricant
- UTECO
- Modello
- ONYX 808
- Année
- 2007
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 850
- Unwinder type
- Turret Automatic flying splice - roll loading system
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic flying splice - roll loading system
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones - 4 fans- 4 mt tunnel - 2 thermo il heaters - automtic recircultion system with LEL control system
- Videocamera
- yes
- Corona treatment
- No
- Web guides
- yes
- Vyscosity control
- yes
- Washing system
- yes
- Inking system
- Close dchamber doctor blades
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- 15 sets of print sleeves
Code Machine | FL738 |
Fabricant | UTECO |
Modello | ONYX 808 |
Année | 2007 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 380 |
Max print repeat (mm) | 850 |
Unwinder type | Turret Automatic flying splice - roll loading system |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret Automatic flying splice - roll loading system |
Max reel diameter rewinder (mm) | 800 |
Drying | 2 zones - 4 fans- 4 mt tunnel - 2 thermo il heaters - automtic recircultion system with LEL control system |
Videocamera | yes |
Corona treatment | No |
Web guides | yes |
Vyscosity control | yes |
Washing system | yes |
Inking system | Close dchamber doctor blades |
Anilox | 12 ceramic anilox sleeves |
Print Sleeves | 15 sets of print sleeves |
