- Código Máquina
- CA215
- Constructor
- COLINES
- Modello
- ALL ROLL EX 1500
- Año
- 2017
- Number of layers
- 5
- Film structure
- A-B-C-B-D
- Material
- Stretch film LLDPE
- Film width (mm)
- 1500
- Speed (m/min)
- 800
- Output (Kg/h)
- 1250
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 55mm
- Description 1
- AC motors, gravimetric dosers Doteco 3 comp
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 80mm
- Description 2
- AC motors, gravimetric dosers Doteco 2 comp
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 120mm
- Description 3
- AC motors, gravimetric dosers Doteco 2 comp
- Extruder 4 Layer ref:
- D
- Screw diam 4
- 55mm
- Description 4
- AC motors, gravimetric dosers Doteco 2 comp
- Head description
- Cloren,
- Die width (mm)
- 2100
- Chill roll unit
- diam 1400mm
- Thickness controll system
- Automatic, Electronic System
- Web guide
- Oscilating frame
- Rewinder description
- Rewinder for Hand reels, Machine reels and Jumbo. Shafts 2" and 3 "
| Código Máquina | CA215 |
| Constructor | COLINES |
| Modello | ALL ROLL EX 1500 |
| Año | 2017 |
| Number of layers | 5 |
| Film structure | A-B-C-B-D |
| Material | Stretch film LLDPE |
| Film width (mm) | 1500 |
| Speed (m/min) | 800 |
| Output (Kg/h) | 1250 |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 55mm |
| Description 1 | AC motors, gravimetric dosers Doteco 3 comp |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 80mm |
| Description 2 | AC motors, gravimetric dosers Doteco 2 comp |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 120mm |
| Description 3 | AC motors, gravimetric dosers Doteco 2 comp |
| Extruder 4 Layer ref: | D |
| Screw diam 4 | 55mm |
| Description 4 | AC motors, gravimetric dosers Doteco 2 comp |
| Head description | Cloren, |
| Die width (mm) | 2100 |
| Chill roll unit | diam 1400mm |
| Thickness controll system | Automatic, Electronic System |
| Web guide | Oscilating frame |
| Rewinder description | Rewinder for Hand reels, Machine reels and Jumbo. Shafts 2" and 3 " |
