A common application is Doypack, or stand up pouch. It is a sachet with a bottom fold and a particular outlay of stiffening welds which creates a modern and universal packaging that can stand up on its own. Other common applications are 3 side weld bags and stand up pouches with square bottoms.
Ask more informations
- Machine Code
- PO32
- Manufacturer
- HUDSON SHARP
- Modello
- HS750SUP
- Year
- 2004
- Type of sealing/bags
- Multiple type
- Bag length
- max 1100mm
- Bag width
- max 600mm
- Unwinder
- Single motor driven
- Cycle / min
- Up to 200
- Additional information type of bags
- 3 side seal, side gusseted with bottom seal and center seal, quad pouch, front zipper
- Note
- Side Gusseting units Bottom sealing bars with photocell 2 Longitudinal sealing bars 3 Cross sealing bars Handle die cutting Cooling bars 2 side bottom sealing K-shape sealers 2 sets of perforating units Pouch bottom glueing device for pet food pouches Front zip device
| Machine Code | PO32 |
| Manufacturer | HUDSON SHARP |
| Modello | HS750SUP |
| Year | 2004 |
| Type of sealing/bags | Multiple type |
| Bag length | max 1100mm |
| Bag width | max 600mm |
| Unwinder | Single motor driven |
| Cycle / min | Up to 200 |
| Additional information type of bags | 3 side seal, side gusseted with bottom seal and center seal, quad pouch, front zipper |
| Note | Side Gusseting units Bottom sealing bars with photocell 2 Longitudinal sealing bars 3 Cross sealing bars Handle die cutting Cooling bars 2 side bottom sealing K-shape sealers 2 sets of perforating units Pouch bottom glueing device for pet food pouches Front zip device |
