** SOLD **
These paper bag making machines fold a paper web into a flat bottom paper bag (or satchel). These bags may be produced in 1 or more layers of paper. These paper bag makers may include an inline printing unit or be equipped to die cut a window in the bag.
Ask more informations
about a similar one
- Machine Code
- FS38
- Manufacturer
- HOLWEG
- Modello
- RS 26
- Year
- 2000
- Width (mm)
- 900
- Materials
- Paper: 25 - 100 gr./
- Feed:
- Reel fed
- Bag length (mm)
- 160 - 760
- Bag width (mm)
- 70 - 380
- Unwinder
- 1000 mm
- Note
- Gusset depth: 80 mm Flap: 13.3 mm Max speed with 4 clamps : 1000 sacs/mn Max speed with 2 clamps: 500 sacs/mn Overall drive system: Standard Slitting: Adjustable perforator Infeed cylinder: Manual pressure Tube forming: Standard plate forming Longitudinal gluing: Hot and cold by nozzle Bottom gluing: Standard Ejection: Motorized table / Unwinder for PP window 4 color print unit W&H QMS 992 Waxing unit Window unit
| Machine Code | FS38 |
| Manufacturer | HOLWEG |
| Modello | RS 26 |
| Year | 2000 |
| Width (mm) | 900 |
| Materials | Paper: 25 - 100 gr./ |
| Feed: | Reel fed |
| Bag length (mm) | 160 - 760 |
| Bag width (mm) | 70 - 380 |
| Unwinder | 1000 mm |
| Note | Gusset depth: 80 mm Flap: 13.3 mm Max speed with 4 clamps : 1000 sacs/mn Max speed with 2 clamps: 500 sacs/mn Overall drive system: Standard Slitting: Adjustable perforator Infeed cylinder: Manual pressure Tube forming: Standard plate forming Longitudinal gluing: Hot and cold by nozzle Bottom gluing: Standard Ejection: Motorized table / Unwinder for PP window 4 color print unit W&H QMS 992 Waxing unit Window unit |
