A duplex laminator will joins 2 layer of web, a triplex lamination machine will join 3 layers together in 1 pass. Coating machines are used to apply a layer of coated material onto a web (support).
Ask more informations
- Machine Code
- LA416
- Manufacturer
- KBA FLEXOTECNICA
- Modello
- EVO LAM
- Year
- 2020
- Application
- Duplex lamination
- Type of lamination/coating
- solventless
- Working width (mm)
- 1300
- First unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- Shaftless driven
- Max diameter reel unwinder
- 1000
- Rewinder type
- Shaftless driven
- Max diameter reel rewinder
- 1000
- Coating unit
- Solventless
- pumping mixing unit
- yes VEA MATRIX
- Corona treatment
- YES
- Note
- Machine new used only for Demo Center sleeve based transfer rolelr with sleeve change system Mixing unit VEA Matrix 2 heating units for coating rollers Chiller for lamionating nip Corona treater Included
| Machine Code | LA416 |
| Manufacturer | KBA FLEXOTECNICA |
| Modello | EVO LAM |
| Year | 2020 |
| Application | Duplex lamination |
| Type of lamination/coating | solventless |
| Working width (mm) | 1300 |
| First unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | Shaftless driven |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Shaftless driven |
| Max diameter reel rewinder | 1000 |
| Coating unit | Solventless |
| pumping mixing unit | yes VEA MATRIX |
| Corona treatment | YES |
| Note | Machine new used only for Demo Center sleeve based transfer rolelr with sleeve change system Mixing unit VEA Matrix 2 heating units for coating rollers Chiller for lamionating nip Corona treater Included |
