In a blown film extruder PE granulates (or other polymer) are melted in an extruder and pushed through a circular die extruding a tube of molten polymer. Tube is then inflated to multiples of its initial diameter and cooled to form a thin film. Bobble is later collapsed and re-winded.
Ask more informations
- Machine Code
- EX686
- Manufacturer
- REIFENHAUSER
- Year
- 2003
- Number of layers
- 3
- Film structure
- ABC
- Material
- LDPE, LLDPE, MDPE Others in blends
- Film Width
- 2300
- Output (Kg/h)
- 400
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 60
- Description 1
- AC motor 60 kW , Gravimetric dosing system Doteco 5 comp
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 80
- Description 2
- AC motor 117 kW , Gravimetric dosing system Doteco 5 comp
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 60
- Description 3
- AC motor 60 kW , Gravimetric dosing system Doteco 5 comp
- Die diam (mm)
- 400 mm + 280mm
- Thickness controll system
- Automatic thickness profile control
- Bubble cage
- Motorized
- Panel for gussets
- Yes
- Take off unit
- oscillating take off unit Reinhold wide 2300 mm with gusseting panels
- Corona treatment
- MERO
- Web guide
- E+L
- Rewinder Type
- Double back to back
- Rewinder max reel diameter
- 1000
- Rewinder description
- Model UFA 01 A1
- Note
- Edge trim shredding Exact and recovery regranulator Macchi Recotrim Chiller Eurochiller
