Rotogravure printing machines (roto or gravure for short) perform a type of intaglio printing process, which involves engraving the image onto a cylinder which become the image carrier. Every printing job will require its dedicated set of engraved cylinders.
Ask more informations
- Machine Code
- RO243
- Manufacturer
- SCHIAVI
- Modello
- PULSAR
- Number of colors
- 6
- Print possibilities
- 6 + lamination in line
- Drive
- Cardan
- Trolley system
- No
- Web width (mm)
- 1450
- Print width (mm)
- 1420
- Print repeat range (mm)
- 400 - 950
- Drying specifications
- DRYING 1 Single hood 2 mt, 1 blowing fa 6500 cu.mt/h, DRYING 2 - Double hood 2 x 2 mt, 2 blowing fan 6500 cu.mt/h,, DRYING 3 Double hood 2 x 2, 5 mt, 2 blowing fan 7000 cu.mt/h
- Drying heat surce
- Thermo il heat exchanger
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Yes
- Register controll
- Yes
- Vyscosity control
- yes automatioc by Gama
- Note
- 6 color with lamination unit inline
Machine Code | RO243 |
Manufacturer | SCHIAVI |
Modello | PULSAR |
Number of colors | 6 |
Print possibilities | 6 + lamination in line |
Drive | Cardan |
Trolley system | No |
Web width (mm) | 1450 |
Print width (mm) | 1420 |
Print repeat range (mm) | 400 - 950 |
Drying specifications | DRYING 1 Single hood 2 mt, 1 blowing fa 6500 cu.mt/h, DRYING 2 - Double hood 2 x 2 mt, 2 blowing fan 6500 cu.mt/h,, DRYING 3 Double hood 2 x 2, 5 mt, 2 blowing fan 7000 cu.mt/h |
Drying heat surce | Thermo il heat exchanger |
Unwinder type | Turret automatic |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 1000 |
Videocamera | Yes |
Register controll | Yes |
Vyscosity control | yes automatioc by Gama |
Note | 6 color with lamination unit inline |
