Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1153
- Manufacturer
- UTECO
- Modello
- ONYX 808
- Year
- 2013
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Automatic Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 gas burners, 2 zones with independent ventilation
- Videocamera
- Yes Grafikontrol with defect control
- Corona treatment
- No
- Web guides
- FIFE
- Vyscosity control
- yes Inkspec
- Washing system
- yes automatic
- Inking system
- Chamber doctor blades - pneumatic pumps
- Anilox
- 11 approx.
| Machine Code | FL1153 |
| Manufacturer | UTECO |
| Modello | ONYX 808 |
| Year | 2013 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 800 |
| Unwinder type | Automatic Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 gas burners, 2 zones with independent ventilation |
| Videocamera | Yes Grafikontrol with defect control |
| Corona treatment | No |
| Web guides | FIFE |
| Vyscosity control | yes Inkspec |
| Washing system | yes automatic |
| Inking system | Chamber doctor blades - pneumatic pumps |
| Anilox | 11 approx. |
