Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1152
- Manufacturer
- UTECO
- Modello
- DIAMOND HP 108
- Year
- 2011
- Number of colors
- 10
- Print possibilityes
- 10+0, 10+10
- Overhaul/renovation
- a retrofit of the electronic parts and a 100x100 print inspection carried out in 2019.
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1550
- Print width (mm)
- 1500
- Min print repeat (mm)
- 420
- Max print repeat (mm)
- 870
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers
- Videocamera
- GRAFYKONTROL
- Web guides
- yes, BST
- Vyscosity control
- Yes
- Washing system
- Yes, automatic
- Inking system
- Closed chamber doctor blades
- Anilox
- 16
- Print Sleeves
- 50
- Note
- Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device 100x100 defect control by Grafikontrol Turning bar 10+10 half width
| Machine Code | FL1152 |
| Manufacturer | UTECO |
| Modello | DIAMOND HP 108 |
| Year | 2011 |
| Number of colors | 10 |
| Print possibilityes | 10+0, 10+10 |
| Overhaul/renovation | a retrofit of the electronic parts and a 100x100 print inspection carried out in 2019. |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1550 |
| Print width (mm) | 1500 |
| Min print repeat (mm) | 420 |
| Max print repeat (mm) | 870 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers |
| Videocamera | GRAFYKONTROL |
| Web guides | yes, BST |
| Vyscosity control | Yes |
| Washing system | Yes, automatic |
| Inking system | Closed chamber doctor blades |
| Anilox | 16 |
| Print Sleeves | 50 |
| Note | Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device 100x100 defect control by Grafikontrol Turning bar 10+10 half width |
