Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1147
- Manufacturer
- EXPERT
- Modello
- ACTIVE 808-GL
- Year
- 2012
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1650
- Print width (mm)
- 1600
- Min print repeat (mm)
- 440
- Max print repeat (mm)
- 850
- Unwinder type
- Single position
- Max reel diameter unwinder (mm)
- 1200
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones , four fans , Gas burner
- Videocamera
- BST
- Washing system
- Yes semiiautomatic
- Inking system
- Water Based
- Anilox
- 8x 160L/cm -vol5, 2x 140L/cm -vol8, 2x 120L/cm -vol9,2
- Note
- Mechanical speed max. 250 m/min Web tension 50 to 600 N Materials : Paper 20 g/m2 upto 50 g/m2, Transfer paper
| Machine Code | FL1147 |
| Manufacturer | EXPERT |
| Modello | ACTIVE 808-GL |
| Year | 2012 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1650 |
| Print width (mm) | 1600 |
| Min print repeat (mm) | 440 |
| Max print repeat (mm) | 850 |
| Unwinder type | Single position |
| Max reel diameter unwinder (mm) | 1200 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones , four fans , Gas burner |
| Videocamera | BST |
| Washing system | Yes semiiautomatic |
| Inking system | Water Based |
| Anilox | 8x 160L/cm -vol5, 2x 140L/cm -vol8, 2x 120L/cm -vol9,2 |
| Note | Mechanical speed max. 250 m/min Web tension 50 to 600 N Materials : Paper 20 g/m2 upto 50 g/m2, Transfer paper |
