Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1146
- Manufacturer
- KBA FLEXOTECNICA
- Modello
- EVO XDS 100
- Year
- 2014
- Number of colors
- 8
- Print possibilityes
- 8 + 0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1050
- Print width (mm)
- 1000
- Min print repeat (mm)
- 280
- Max print repeat (mm)
- 800
- Unwinder type
- Single
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret Automatic with roll unloading system
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones - 4 fans final drying tunnwl -electric heaters
- Corona treatment
- AFS
- Web guides
- yes in and out
- Washing system
- Yes
- Inking system
- Closed chamber doctor blades and ceramic anilox sleeves
- Anilox
- 19
- Print Sleeves
- 218 ( 179 for plates 1.14 mm and 39 for plates 2.54 mm )
- Note
- Materials : OPP 20 - 40 my HDPE 30 - 150 my LDPE 30 - 200 my CPP 30 - 90 my OPTION : DESBA TEC - destillation unit for the waste liquids from the cleaning unit of the press
| Machine Code | FL1146 |
| Manufacturer | KBA FLEXOTECNICA |
| Modello | EVO XDS 100 |
| Year | 2014 |
| Number of colors | 8 |
| Print possibilityes | 8 + 0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1050 |
| Print width (mm) | 1000 |
| Min print repeat (mm) | 280 |
| Max print repeat (mm) | 800 |
| Unwinder type | Single |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret Automatic with roll unloading system |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones - 4 fans final drying tunnwl -electric heaters |
| Corona treatment | AFS |
| Web guides | yes in and out |
| Washing system | Yes |
| Inking system | Closed chamber doctor blades and ceramic anilox sleeves |
| Anilox | 19 |
| Print Sleeves | 218 ( 179 for plates 1.14 mm and 39 for plates 2.54 mm ) |
| Note | Materials : OPP 20 - 40 my HDPE 30 - 150 my LDPE 30 - 200 my CPP 30 - 90 my OPTION : DESBA TEC - destillation unit for the waste liquids from the cleaning unit of the press |
