Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1145
- Manufacturer
- UTECO
- Modello
- ONYX 808
- Year
- 2010
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 360
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones 4 fans , final tunel 4mt long , 2 gas burners , automatic air recirculation system with LEL control
- Videocamera
- yes BST
- Web guides
- yes in and out
- Vyscosity control
- Yes automatic
- Washing system
- Yes auto wash up system
- Inking system
- Closed chamber doctor blades and ceramic anilox rollers N° 8Ink Pumps.
- Anilox
- 8 ceramic anilox sleeves as follow s 1x 90 l/cm , 1 x- 100 l/cm , 1x 140 l/cm , 1x 180 l/cm, 2x 200 l/cm, 1 x 340l/cm , 1 x 420 l/cm
- Print Sleeves
- 8 x 540 mm, 8 x 600 mm, 8 x 640 mm.
| Machine Code | FL1145 |
| Manufacturer | UTECO |
| Modello | ONYX 808 |
| Year | 2010 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 360 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones 4 fans , final tunel 4mt long , 2 gas burners , automatic air recirculation system with LEL control |
| Videocamera | yes BST |
| Web guides | yes in and out |
| Vyscosity control | Yes automatic |
| Washing system | Yes auto wash up system |
| Inking system | Closed chamber doctor blades and ceramic anilox rollers N° 8Ink Pumps. |
| Anilox | 8 ceramic anilox sleeves as follow s 1x 90 l/cm , 1 x- 100 l/cm , 1x 140 l/cm , 1x 180 l/cm, 2x 200 l/cm, 1 x 340l/cm , 1 x 420 l/cm |
| Print Sleeves | 8 x 540 mm, 8 x 600 mm, 8 x 640 mm. |
