Flexo printers CI (Central Impression) are especially suitable in markets which require process jobs and flexibility (involve productions of small lots). In particular, technological improvements of last 15 years have re-shaped CI flexo presses both in their mechanical construction and in its controls. This improved their printing quality, drastically reduced change over times and consequently downsized their "minimum economical lot".
Ask more informations
- Machine Code
- FL1122
- Manufacturer
- KBA FLEXOTECNICA
- Modello
- EVO XD
- Year
- 2017
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic with roll loading system
- Rewinder type
- Turret Automatic with roll unloading system
- Drying
- 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger
- Videocamera
- YES AVT 100% INSPECTION
- Web guides
- Yes in and out
- Vyscosity control
- yes GAMA
- Washing system
- Yes
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- approx 100
| Machine Code | FL1122 |
| Manufacturer | KBA FLEXOTECNICA |
| Modello | EVO XD |
| Year | 2017 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic with roll loading system |
| Rewinder type | Turret Automatic with roll unloading system |
| Drying | 2 zones , 4 fans , final tunnel 5 mt length , 2 Gas Burners 200.000 Kcl/h each, Automatic Air recirculation system with LEL controls on each zone Zellweger |
| Videocamera | YES AVT 100% INSPECTION |
| Web guides | Yes in and out |
| Vyscosity control | yes GAMA |
| Washing system | Yes |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | approx 100 |
