** SOLD **
Flexographic printing machines (often abbreviated as flexo press) perform a printing process which utilizes a flexible relief plate to transfer ink to printed substrate. Every printing job will require its dedicated set of plates.
Ask more informations
about a similar one
- Machine Code
- FL890
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- NOVOFLEX
- Year
- 2002
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1050
- Print width (mm)
- 1000
- Min print repeat (mm)
- 300
- Min print repeat (mm)
- 300
- Max print repeat (mm)
- 760
- Unwinder type
- TURRET
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- TURRET
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Eltromat from 2016 with registration system
- Corona treatment
- Softal
- Vyscosity control
- no
- Washing system
- no
- Inking system
- Closed cha,ber doctor blades
- Inking system
- Closed chamber doctor baldes
- Anilox
- 43 ceramic anilox sleeves as follows 2 x 400 l/cm Vol. 4,3 ; 6x 400 L/cm-V 4,5 ; 4x 400 l/cm V.4,7; 4x 320 l/cm-V.5 ; 1x 320 l/cm-V5,5; 1x 320 l/cm V.5,7 ; 1x 315 l/cm-Vol.5,2 ; 2x 315 l/cm -V. 5,8; 2 x 285 l/cm.V.9,5 ; 4x 280 l/cm-V.8,5 ; 1x 280 l/cm-V.7 ; 2x 220 l/cm V.9,1 ;1x 180 l/cm-v.9,2 ; 1x 180 l/cm.V.9,6 ; 3x 160 l/cm-v.12 ; 2x 160 l/cm-V.12,3 ; 2x 140 l/cm -v.14 ; 1x 140 l/cm v.12,3 ; 2 x100 l/cm-v.14,2; 2x 100 l/cm-v.15,1; 1x 100 l/cm-v.22
- Anilox
- 45 Anilox sleeves: 5x100 L/cm, 3x140 L/cm, 5x160 L/cm, 2x180 L/cm, 2x220 L/cm, 5x280 L/cm, 2x285 L/cm, 3x315 L/cm, 6x320 L/cm, 12x400 L/cm
- Print Sleeves
- Tot 292 print repeats: 300x16,315x16, 325x15, 330x7, 340x8, 350x8, 365x8, 380x8, 400x16, 410x16, 420x16, 425x8, 430x16, 440x8, 450x16, 460x8, 470x16, 480x8, 490x12, 500x10, 520x16, 540x8, 560x8, 580x8, 640x8, 680x8, 690x8
| Machine Code | FL890 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | NOVOFLEX |
| Year | 2002 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1050 |
| Print width (mm) | 1000 |
| Min print repeat (mm) | 300 |
| Min print repeat (mm) | 300 |
| Max print repeat (mm) | 760 |
| Unwinder type | TURRET |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | TURRET |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | Eltromat from 2016 with registration system |
| Corona treatment | Softal |
| Vyscosity control | no |
| Washing system | no |
| Inking system | Closed cha,ber doctor blades |
| Inking system | Closed chamber doctor baldes |
| Anilox | 43 ceramic anilox sleeves as follows 2 x 400 l/cm Vol. 4,3 ; 6x 400 L/cm-V 4,5 ; 4x 400 l/cm V.4,7; 4x 320 l/cm-V.5 ; 1x 320 l/cm-V5,5; 1x 320 l/cm V.5,7 ; 1x 315 l/cm-Vol.5,2 ; 2x 315 l/cm -V. 5,8; 2 x 285 l/cm.V.9,5 ; 4x 280 l/cm-V.8,5 ; 1x 280 l/cm-V.7 ; 2x 220 l/cm V.9,1 ;1x 180 l/cm-v.9,2 ; 1x 180 l/cm.V.9,6 ; 3x 160 l/cm-v.12 ; 2x 160 l/cm-V.12,3 ; 2x 140 l/cm -v.14 ; 1x 140 l/cm v.12,3 ; 2 x100 l/cm-v.14,2; 2x 100 l/cm-v.15,1; 1x 100 l/cm-v.22 |
| Anilox | 45 Anilox sleeves: 5x100 L/cm, 3x140 L/cm, 5x160 L/cm, 2x180 L/cm, 2x220 L/cm, 5x280 L/cm, 2x285 L/cm, 3x315 L/cm, 6x320 L/cm, 12x400 L/cm |
| Print Sleeves | Tot 292 print repeats: 300x16,315x16, 325x15, 330x7, 340x8, 350x8, 365x8, 380x8, 400x16, 410x16, 420x16, 425x8, 430x16, 440x8, 450x16, 460x8, 470x16, 480x8, 490x12, 500x10, 520x16, 540x8, 560x8, 580x8, 640x8, 680x8, 690x8 |
