NEW LONG TS5525-S+2H SOS Papier Blockboden / Kreuzboden Beutelmaschine // Paper bag making SOS // Bag making // Gebrauchte Maschinen // Tecno Converting 2000 S.r.l.

Maschinencode: SO337
Hersteller: NEW LONG
Modello: TS5525-S+2H
Baujahr: 2014
Width (mm): 810
Feed:: Sheet fed
Handel unit: No
Bag length max (mm): 510
Bag length min (mm): 205
Bag width max (mm): 200
Bag width min (mm): 100
Bottom width max (mm): 140
Bottom width (mm): 60
Cycle / min: 120-240 bags/min
Note: Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator.

Maschinencode	SO337
Hersteller	NEW LONG
Modello	TS5525-S+2H
Baujahr	2014
Width (mm)	810
Feed:	Sheet fed
Handel unit	No
Bag length max (mm)	510
Bag length min (mm)	205
Bag width max (mm)	200
Bag width min (mm)	100
Bottom width max (mm)	140
Bottom width (mm)	60
Cycle / min	120-240 bags/min
Note	Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator.
