- Maschinencode
- LA450
- Hersteller
- KYMC
- Modello
- COMBI 1300
- Baujahr
- 2006
- Application
- Duplex lamination
- Type of lamination/coating
- COMBI / INTECHANGEABLE TROLLEY
- Working width (mm)
- 1300
- Speed
- 200 m/min
- First unwinder type
- Single
- Max diameter reel unwinder
- 800
- Secondary unwinder type
- Single
- Max diameter reel unwinder
- 800
- Rewinder type
- Single
- Max diameter reel rewinder
- 800
- Coating unit
- 2 fixed application units : Gravure roller and Solventless
- Drying
- Length of drying hood - 6,4 meters, max temp. 100
- Register controll
- No
- pumping mixing unit
- 2 components mixing and pumping unit for solventless
- Corona treatment
- 1 corona treatment, SHERMAN
- Note
- Adhesive thickness measurement - Manual by QA LAB Core diameter - 76/152 Max. tension - 20 daN Max. weight unwinder - 600 kg Max. weight rewinder - 600 kg
| Maschinencode | LA450 |
| Hersteller | KYMC |
| Modello | COMBI 1300 |
| Baujahr | 2006 |
| Application | Duplex lamination |
| Type of lamination/coating | COMBI / INTECHANGEABLE TROLLEY |
| Working width (mm) | 1300 |
| Speed | 200 m/min |
| First unwinder type | Single |
| Max diameter reel unwinder | 800 |
| Secondary unwinder type | Single |
| Max diameter reel unwinder | 800 |
| Rewinder type | Single |
| Max diameter reel rewinder | 800 |
| Coating unit | 2 fixed application units : Gravure roller and Solventless |
| Drying | Length of drying hood - 6,4 meters, max temp. 100 |
| Register controll | No |
| pumping mixing unit | 2 components mixing and pumping unit for solventless |
| Corona treatment | 1 corona treatment, SHERMAN |
| Note | Adhesive thickness measurement - Manual by QA LAB Core diameter - 76/152 Max. tension - 20 daN Max. weight unwinder - 600 kg Max. weight rewinder - 600 kg |
