- Maschinencode
- RO255
- Hersteller
- ACOM
- Modello
- RG EXCEL
- Baujahr
- 2014
- Number of colors
- 6
- Drive
- Electronic shaft
- Trolley system
- Yes
- Web width (mm)
- 850
- Print width (mm)
- 800
- Print repeat range (mm)
- 500 - 800
- Drying specifications
- Four Units 2 to 5 : single drying hood 2,2 mt length ,1 blowing fan, 1 gas burner , 2 chill rollers- Two Units 1 and 6 Extended drying hood 3, 5 mt length, 2 gas burners, 3 chill rollers .- Each unit with independent air recirculation system
- Drying heat surce
- Gas burners
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Register controll
- ELTROMAT DGC 700
- Note
- Materials PET 12- 40 microns, BOPP 15-50 microns. Paper 40- 140 gsm - Only water based inks infeed Driven section Outfeed driven nip section Web guides infeed and outfeed OPG type
Maschinencode | RO255 |
Hersteller | ACOM |
Modello | RG EXCEL |
Baujahr | 2014 |
Number of colors | 6 |
Drive | Electronic shaft |
Trolley system | Yes |
Web width (mm) | 850 |
Print width (mm) | 800 |
Print repeat range (mm) | 500 - 800 |
Drying specifications | Four Units 2 to 5 : single drying hood 2,2 mt length ,1 blowing fan, 1 gas burner , 2 chill rollers- Two Units 1 and 6 Extended drying hood 3, 5 mt length, 2 gas burners, 3 chill rollers .- Each unit with independent air recirculation system |
Drying heat surce | Gas burners |
Unwinder type | Turret Automatic |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 1000 |
Register controll | ELTROMAT DGC 700 |
Note | Materials PET 12- 40 microns, BOPP 15-50 microns. Paper 40- 140 gsm - Only water based inks infeed Driven section Outfeed driven nip section Web guides infeed and outfeed OPG type |
