- Maschinencode
- FL0928
- Hersteller
- UTECO
- Modello
- TOPAZ 608
- Baujahr
- 2012
- Number of colors
- 6
- Print possibilityes
- 6 color water or solvent based
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1450
- Print width (mm)
- 1410
- Min print repeat (mm)
- 390
- Max print repeat (mm)
- 850
- Unwinder type
- Turret manual
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones - 4 fans- Final tunnel 4 mt- 2 gas burners
- Videocamera
- Yes
- Web guides
- yes in and out
- Vyscosity control
- No
- Washing system
- Yes included
- Inking system
- Closed chamber doctor blades
- Anilox
- 6 ceramic anilox sleeves
- Print Sleeves
- 1 set of sleeves
- Note
- Materials Paper from 60 up to 210 gsm Printing speed: up to 300m/min Upper supporting frame for installing Chiller, web cleaner and electric boxes. Embossing unit in option
| Maschinencode | FL0928 |
| Hersteller | UTECO |
| Modello | TOPAZ 608 |
| Baujahr | 2012 |
| Number of colors | 6 |
| Print possibilityes | 6 color water or solvent based |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1450 |
| Print width (mm) | 1410 |
| Min print repeat (mm) | 390 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret manual |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones - 4 fans- Final tunnel 4 mt- 2 gas burners |
| Videocamera | Yes |
| Web guides | yes in and out |
| Vyscosity control | No |
| Washing system | Yes included |
| Inking system | Closed chamber doctor blades |
| Anilox | 6 ceramic anilox sleeves |
| Print Sleeves | 1 set of sleeves |
| Note | Materials Paper from 60 up to 210 gsm Printing speed: up to 300m/min Upper supporting frame for installing Chiller, web cleaner and electric boxes. Embossing unit in option |
