- Machine code
- SR613
- Manufacturer
- KAMPF
- Year
- 2010
- Working width (mm)
- 2300
- Speed
- 400m/min
- Max diameter reel unwinder
- 1500
- Max diameter reel rewinder
- 1000
- Min slit width
- 50
- Note
- Expansion shafts: -1500/ 1450mm - 2 pcs 76/1800- 2pcs - 76/2300 -1 pc - 76/1450-1 pc - 76/1000 -1 pc - 76/900-1 pc - Knife block 2200mm, stroke 5mm - Pneumatic heads - 10 pcs - Core size on unwinding: a)76 - 300 mm - The size of the wound core: a)76 or 150 mm - Grammage range: 40 - 500 gsm
Machine code | SR613 |
Manufacturer | KAMPF |
Year | 2010 |
Working width (mm) | 2300 |
Speed | 400m/min |
Max diameter reel unwinder | 1500 |
Max diameter reel rewinder | 1000 |
Min slit width | 50 |
Note | Expansion shafts: -1500/ 1450mm - 2 pcs 76/1800- 2pcs - 76/2300 -1 pc - 76/1450-1 pc - 76/1000 -1 pc - 76/900-1 pc - Knife block 2200mm, stroke 5mm - Pneumatic heads - 10 pcs - Core size on unwinding: a)76 - 300 mm - The size of the wound core: a)76 or 150 mm - Grammage range: 40 - 500 gsm |
