- Machine code
- BO57
- Manufacturer
- BRUCKNER
- Year
- 1990
- Number of layers
- 3
- Overhaul/renovation
- several
- Film structure
- A B C
- Material
- BOPP
- Output
- 2500 kG / H
- Width (mm)
- 7400
- Extruder 1 Description
- 1 X 200 MM diam L/D 21 + 1 sequence 1 x 250 L/D 20
- Extruder 2 Description
- 1 x90 coex
- Extruder 3 Description
- 1 x 90 coex
- Head description
- 7 heating zones - 45 Kw heating power - lips 1,7 - 3,5 mm
- Die width
- 1054 mm
- Thickness controll system
- automatic SIMPLAST head by 37 heating bolts Two thickness controls new by Electronic system
- Chill roll unit
- width 1400 mm diam 2.400 mm
- MDO description
- pulling unit thermo heated calenders, rollers width 1200 mm, MDO ratio 1: 1/ 10:1- slow section 2 x 60 m/ min ;high speed section 9 x 250 m/min, Preheating calenders 18 , 6 pulling rollers , 2 stabiizing rollersn
- TDO description
- Max stretchin width 8500 mm, effective max width capacxity 6700 - 7500 mm, 7 heating zones by air blowers and thermo oil heaters
- Corona treatment
- yes two corona treaters
- Flame treatment
- Yes
- Rewinder width
- 7200 mm
- Rewinder description
- Diam mandrels 450mm.Lenght mandrels 7800mm. Winding speed 250m/min. Tension film 150/700N. 2 alternating winding stations approx 40 shafts for rewinder
- Slitter
- year 1988, 7200 max width film; Diam unwinder 1000mm - 900 diam rewinder. 200 mm min cut. 2000mm max cut. Speed 800m/min
- Note
- Trim exhausting grinding and recirculating unit Upgrade with track and chain fok4.4.7 New Simoreg drives of all motors in 2007 2 corona top treaters Available large set of spare parts as screws Rollers of MDO
| Machine code | BO57 |
| Manufacturer | BRUCKNER |
| Year | 1990 |
| Number of layers | 3 |
| Overhaul/renovation | several |
| Film structure | A B C |
| Material | BOPP |
| Output | 2500 kG / H |
| Width (mm) | 7400 |
| Extruder 1 Description | 1 X 200 MM diam L/D 21 + 1 sequence 1 x 250 L/D 20 |
| Extruder 2 Description | 1 x90 coex |
| Extruder 3 Description | 1 x 90 coex |
| Head description | 7 heating zones - 45 Kw heating power - lips 1,7 - 3,5 mm |
| Die width | 1054 mm |
| Thickness controll system | automatic SIMPLAST head by 37 heating bolts Two thickness controls new by Electronic system |
| Chill roll unit | width 1400 mm diam 2.400 mm |
| MDO description | pulling unit thermo heated calenders, rollers width 1200 mm, MDO ratio 1: 1/ 10:1- slow section 2 x 60 m/ min ;high speed section 9 x 250 m/min, Preheating calenders 18 , 6 pulling rollers , 2 stabiizing rollersn |
| TDO description | Max stretchin width 8500 mm, effective max width capacxity 6700 - 7500 mm, 7 heating zones by air blowers and thermo oil heaters |
| Corona treatment | yes two corona treaters |
| Flame treatment | Yes |
| Rewinder width | 7200 mm |
| Rewinder description | Diam mandrels 450mm.Lenght mandrels 7800mm. Winding speed 250m/min. Tension film 150/700N. 2 alternating winding stations approx 40 shafts for rewinder |
| Slitter | year 1988, 7200 max width film; Diam unwinder 1000mm - 900 diam rewinder. 200 mm min cut. 2000mm max cut. Speed 800m/min |
| Note | Trim exhausting grinding and recirculating unit Upgrade with track and chain fok4.4.7 New Simoreg drives of all motors in 2007 2 corona top treaters Available large set of spare parts as screws Rollers of MDO |
