3 layers COLINES POLYCAST CFC/210 УСТАНОВКИ ДЛЯ ПОЛИВНЫХ ПЛЁНОК

Machine code
CA243
Manufacturer
COLINES
Modello
POLYCAST CFC/210
Year
2014
Number of layers
3
Film structure
ABC
Material
CPP and CPE
Film width (mm)
2100
Speed (m/min)
450m/min
Output (Kg/h)
700 + 200 + 200 1100 kg/h max gross throughput. Max approx net throughput on 22my 2100mm : 850 kg/h
Extruder 1 Layer ref:
A
Screw diam 1
80mm
Extruder 2 Layer ref:
B
Screw diam 2
140mm
Description 2
Single screw extruder ( bimettalic barrel and screw) .Hydraulic Screen Changers for longer changeover time
Extruder 3 Layer ref:
C
Screw diam 3
80mm
Head description
Cloeren USA feedblock and flat extrusion die with automatic adjustment via thermal bolts, internal deckle systems 200mm per side, with die splitting for easy cleaning
Die width (mm)
2600mm
Chill roll unit
Automatic chill roll speed regulation for thickness measurement. Chill Roll Unit diam 1000mm and 300mm, width 2700mm
Thickness controll system
Automatic thickness profile control. Electronic Systems thickness gauge with support structure and autodiagnosis unit a
Web guide
Oscillating Frame
Rewinder max reel diameter (mm)
1000mm
Rewinder description
Turret Winder Jumbowind with useful width 2100mm, pneumatic air shafts, extraction. Hydraulic trolley for air-shafts extraction, Anti-static bars
Note
Cooling air blade Thickness 12-200my Air shafts diam 6" Water Thermoregulation unit Recycling unit for trimmed edges on intermediate and final trim unit to be refed into the main extruder General electric control equipment in air-conditioned container Supervision system with HMI that includes Supervisor, Fast Adjust, LC live check, Teleservice Centralized Control desk of the line
Machine code CA243
Manufacturer COLINES
Modello POLYCAST CFC/210
Year 2014
Number of layers 3
Film structure ABC
Material CPP and CPE
Film width (mm) 2100
Speed (m/min) 450m/min
Output (Kg/h) 700 + 200 + 200 1100 kg/h max gross throughput. Max approx net throughput on 22my 2100mm : 850 kg/h
Extruder 1 Layer ref: A
Screw diam 1 80mm
Extruder 2 Layer ref: B
Screw diam 2 140mm
Description 2 Single screw extruder ( bimettalic barrel and screw) .Hydraulic Screen Changers for longer changeover time
Extruder 3 Layer ref: C
Screw diam 3 80mm
Head description Cloeren USA feedblock and flat extrusion die with automatic adjustment via thermal bolts, internal deckle systems 200mm per side, with die splitting for easy cleaning
Die width (mm) 2600mm
Chill roll unit Automatic chill roll speed regulation for thickness measurement. Chill Roll Unit diam 1000mm and 300mm, width 2700mm
Thickness controll system Automatic thickness profile control. Electronic Systems thickness gauge with support structure and autodiagnosis unit a
Web guide Oscillating Frame
Rewinder max reel diameter (mm) 1000mm
Rewinder description Turret Winder Jumbowind with useful width 2100mm, pneumatic air shafts, extraction. Hydraulic trolley for air-shafts extraction, Anti-static bars
Note Cooling air blade Thickness 12-200my Air shafts diam 6" Water Thermoregulation unit Recycling unit for trimmed edges on intermediate and final trim unit to be refed into the main extruder General electric control equipment in air-conditioned container Supervision system with HMI that includes Supervisor, Fast Adjust, LC live check, Teleservice Centralized Control desk of the line
