- Machine code
- CA169
- Manufacturer
- BATTENFELD
- Year
- 1991
- Number of layers
- 5
- Overhaul/renovation
- Further modifications 2007, 2011
- Film structure
- CBBDA, BDAAC, DBAAC, CDBDA
- Material
- CPP, STRETCH FILM, Barrier fim
- Film width (mm)
- 2000
- Speed (m/min)
- 300 m/min
- Output (Kg/h)
- 750 kg/hr
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 120mm diam
- Description 1
- 30:1 L:D / 187 kW
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 90mm diam
- Description 2
- 30:1 L:D / 112 kW
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 90mm diam
- Description 3
- 30:1 L:D / 112 kW
- Extruder 4 Layer ref:
- D
- Screw diam 4
- 60mm diam
- Description 4
- 30:1 L:D / 45 kW
- Die width (mm)
- 1900mm
- Chill roll unit
- 2 chill rollers, diameter 600mm
- Corona treatment
- Sherman Ceramic roller, GT 220
- Web guide
- Fife oscillating frame with RMP modified drive
- Note
- Spare die - EDI autoflex, 1900mm wide Feedblock - Cloeren, dual plane, adjustable vane, 5 layer
| Machine code | CA169 |
| Manufacturer | BATTENFELD |
| Year | 1991 |
| Number of layers | 5 |
| Overhaul/renovation | Further modifications 2007, 2011 |
| Film structure | CBBDA, BDAAC, DBAAC, CDBDA |
| Material | CPP, STRETCH FILM, Barrier fim |
| Film width (mm) | 2000 |
| Speed (m/min) | 300 m/min |
| Output (Kg/h) | 750 kg/hr |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 120mm diam |
| Description 1 | 30:1 L:D / 187 kW |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 90mm diam |
| Description 2 | 30:1 L:D / 112 kW |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 90mm diam |
| Description 3 | 30:1 L:D / 112 kW |
| Extruder 4 Layer ref: | D |
| Screw diam 4 | 60mm diam |
| Description 4 | 30:1 L:D / 45 kW |
| Die width (mm) | 1900mm |
| Chill roll unit | 2 chill rollers, diameter 600mm |
| Corona treatment | Sherman Ceramic roller, GT 220 |
| Web guide | Fife oscillating frame with RMP modified drive |
| Note | Spare die - EDI autoflex, 1900mm wide Feedblock - Cloeren, dual plane, adjustable vane, 5 layer |
