NEW LONG TS5525-S+2H Sacchettatrice per sacchetti a fondo quadro

Codice Macchina
SO337
Manufacturer
NEW LONG
Modello
TS5525-S+2H
Year
2014
Larghezza (mm)
810
Alimentazione:
Sheet fed
Maniglia
No
Lunghezza max (mm) sacchetto
510
Lunghezza min (mm) sacchetto
205
Larghezza max(mm) sacchetto
200
Larghezza min (mm) sacchetto
100
Larghezza fondo max (mm) sacchetto
140
Larghezza fondo min (mm) sacchetto
60
Cicli/min
120-240 bags/min
Ulteriori informazioni
Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator.
Codice Macchina SO337
Manufacturer NEW LONG
Modello TS5525-S+2H
Year 2014
Larghezza (mm) 810
Alimentazione: Sheet fed
Maniglia No
Lunghezza max (mm) sacchetto 510
Lunghezza min (mm) sacchetto 205
Larghezza max(mm) sacchetto 200
Larghezza min (mm) sacchetto 100
Larghezza fondo max (mm) sacchetto 140
Larghezza fondo min (mm) sacchetto 60
Cicli/min 120-240 bags/min
Ulteriori informazioni Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator.
