- Codice Macchina
- EC48
- Manufacturer
- KUHNE/ SML
- Year
- 2006
- Larghezza (mm)
- 1180
- Unita di spalmatura / accoppiamento 1
- 3 layer film (A-B-A) - B extr: 105mm diam (extrusion capacity 650 Kg/h), L/D 30. Melt pump, 3 components gravimetric unit make: Montan, hydraulic screen changer - A extr 90mm diam L/D30 (extrusion capacity 250 Kg/h). Melt pump, 3 components gravimetric unit make: Montan, hydraulic screen changer Extruder make: Kuhne Extrusion die Cloren Casting unit SML net film width 800-1180mm chill roll width 1600mm. This is cast extrusion unit Vacuum box and air knife at exit or extrusion die.
- Unita di spalmatura / accoppiamento 2
- Monolayer screw diam 75mm L/D37, hydraulic screen changer, gravimetric dosing system 4 comp make: Montan. Output 700kg/h Extruder make: Kuhne Extrusion die Cloren Casting unit SML extrusion width700-1100 chill roll width 1600mm
- Trattamento
- Corona AFS
- Descrizione svolgitore primario
- Turret, 1000mm max siam. 1500Kg ax weight of reel
- Descrizione avvolgitore
- Turret, 1000mm max siam. 1500Kg ax weight of reel
- Struttura del prodotto / Materiali
- Cast + extrusion coating or Extrusion coating
- Ulteriori informazioni
- Machine for cast coating (first cast extrusion and then extrusion coating on film) or for extrusion coating on existing material Processing of polymers in a temperature range of 90-300°C in extrusion Possible layer structures: Cast extrusion ABA with first extrusion unit + C coating with second unit. Main extruder : mono film if necessary with tensilized film / 3 layer film (A-B-A) if necessary with tensilized film Optical inspection system for defects (e.g. gels, inclusions etc) Beta rays thickness control system 1 Polymer dryer 5000L,1 x 2500L, 3x400L, E+L web guides
| Codice Macchina | EC48 |
| Manufacturer | KUHNE/ SML |
| Year | 2006 |
| Larghezza (mm) | 1180 |
| Unita di spalmatura / accoppiamento 1 | 3 layer film (A-B-A) - B extr: 105mm diam (extrusion capacity 650 Kg/h), L/D 30. Melt pump, 3 components gravimetric unit make: Montan, hydraulic screen changer - A extr 90mm diam L/D30 (extrusion capacity 250 Kg/h). Melt pump, 3 components gravimetric unit make: Montan, hydraulic screen changer Extruder make: Kuhne Extrusion die Cloren Casting unit SML net film width 800-1180mm chill roll width 1600mm. This is cast extrusion unit Vacuum box and air knife at exit or extrusion die. |
| Unita di spalmatura / accoppiamento 2 | Monolayer screw diam 75mm L/D37, hydraulic screen changer, gravimetric dosing system 4 comp make: Montan. Output 700kg/h Extruder make: Kuhne Extrusion die Cloren Casting unit SML extrusion width700-1100 chill roll width 1600mm |
| Trattamento | Corona AFS |
| Descrizione svolgitore primario | Turret, 1000mm max siam. 1500Kg ax weight of reel |
| Descrizione avvolgitore | Turret, 1000mm max siam. 1500Kg ax weight of reel |
| Struttura del prodotto / Materiali | Cast + extrusion coating or Extrusion coating |
| Ulteriori informazioni | Machine for cast coating (first cast extrusion and then extrusion coating on film) or for extrusion coating on existing material Processing of polymers in a temperature range of 90-300°C in extrusion Possible layer structures: Cast extrusion ABA with first extrusion unit + C coating with second unit. Main extruder : mono film if necessary with tensilized film / 3 layer film (A-B-A) if necessary with tensilized film Optical inspection system for defects (e.g. gels, inclusions etc) Beta rays thickness control system 1 Polymer dryer 5000L,1 x 2500L, 3x400L, E+L web guides |
