- Codice Macchina
- RO117
- Manufacturer
- CERUTTI
- Modello
- 48 R
- Year
- 1988
- Numero di colori
- 9
- Larghezza nastro (mm)
- 1390
- Larghezza stampa (mm)
- 1320
- Formato stampa (mm)
- 450-1000 mm
- Drying specifications
- one drier c.m./h 10000 print station from 1 at 6 - drier length 2600mm ; double drier c.m./h 15800 for print station 7 -8 - drier length 4500mm.
- Drying heat surce
- from 1 to 6 print station with steam – from printing station 7-8 with gas heaters
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Videocamera
- Grafikontrol
- Controllo di registro
- Crosfield
- Vyscosity control
- Crosfield
- Trattamento Corona
- No
- Cilindri stampa
- 80
- Ulteriori informazioni
- Print speed: 350/400 mt/min. On station 9th solvent laminating unit solventless Nordmeccanica.Preconditioning unit on unwinder.Gravure cylinders: Nr. 80 (available on option up to 200 cylinders). Cylinders shaft: Nr. 37 in two sizes 1070 and 1390 mm.Pressure rollers: 60 in different sizes.4 air shafts 70 mm + 6 air shafts ; 76 mm + 6 air shafts ;152 mm. No. 12 ink pumps, 15 ink trays + splashguards for 3 sizes
| Codice Macchina | RO117 |
| Manufacturer | CERUTTI |
| Modello | 48 R |
| Year | 1988 |
| Numero di colori | 9 |
| Larghezza nastro (mm) | 1390 |
| Larghezza stampa (mm) | 1320 |
| Formato stampa (mm) | 450-1000 mm |
| Drying specifications | one drier c.m./h 10000 print station from 1 at 6 - drier length 2600mm ; double drier c.m./h 15800 for print station 7 -8 - drier length 4500mm. |
| Drying heat surce | from 1 to 6 print station with steam – from printing station 7-8 with gas heaters |
| Unwinder type | Turret automatic |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Videocamera | Grafikontrol |
| Controllo di registro | Crosfield |
| Vyscosity control | Crosfield |
| Trattamento Corona | No |
| Cilindri stampa | 80 |
| Ulteriori informazioni | Print speed: 350/400 mt/min. On station 9th solvent laminating unit solventless Nordmeccanica.Preconditioning unit on unwinder.Gravure cylinders: Nr. 80 (available on option up to 200 cylinders). Cylinders shaft: Nr. 37 in two sizes 1070 and 1390 mm.Pressure rollers: 60 in different sizes.4 air shafts 70 mm + 6 air shafts ; 76 mm + 6 air shafts ;152 mm. No. 12 ink pumps, 15 ink trays + splashguards for 3 sizes |
