- Code Machine
- SO337
- Fabricant
- NEW LONG
- Modello
- TS5525-S+2H
- Année
- 2014
- Width (mm)
- 810
- Feed:
- Sheet fed
- Handel unit
- No
- Bag length max (mm)
- 510
- Bag length min (mm)
- 205
- Bag width max (mm)
- 200
- Bag width min (mm)
- 100
- Bottom width max (mm)
- 140
- Bottom width (mm)
- 60
- Cycle / min
- 120-240 bags/min
- Note
- Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator.
| Code Machine | SO337 |
| Fabricant | NEW LONG |
| Modello | TS5525-S+2H |
| Année | 2014 |
| Width (mm) | 810 |
| Feed: | Sheet fed |
| Handel unit | No |
| Bag length max (mm) | 510 |
| Bag length min (mm) | 205 |
| Bag width max (mm) | 200 |
| Bag width min (mm) | 100 |
| Bottom width max (mm) | 140 |
| Bottom width (mm) | 60 |
| Cycle / min | 120-240 bags/min |
| Note | Sheet size maximum sheet width - 810mm maximum sheet diameter - 1200mm sheet basis weight : inner layer paper 50-70g/m2 outer layer 60-90g/m2 2P 110-150g/m2 Paper tube inner diameter :70mm Bottom sheet size Max sheet width 200mm - 240mm maximum sheet diameter: 600mm sheet basis weight 70-90g/m2 Paper tube inner diameter 76mm The maximum capability depends on several conditions such as basis weight, printing precision, envelope shape, and the skill level of the operator. |
WINDMÖLLER & HÖLSCHER TRIUMPH 5A
-
Code Machine: SO331
-
Année: 1970
-
Bag width max (mm): 450
WINDMÖLLER & HÖLSCHER TRIUMPH 2
-
Code Machine: SO329
-
Année: 1988
-
Bag width max (mm): 75
TOKYO PACK PAXTER SBD 50
-
Code Machine: SO307
-
Année: 1993
-
Width (mm): 1070
WINDMÖLLER & HÖLSCHER TRIUMPH3
-
Code Machine: SO323
-
Année: 1974
-
Bag width max (mm): 250
WINDMÖLLER & HÖLSCHER TRIUMPH 3A
-
Code Machine: SO324
-
Année: 1985
-
Bag width max (mm): 300
NEW LONG 345T
-
Code Machine: SO309
-
Année: 1989
-
Width (mm): 1250
