- Code Machine
- LA452
- Fabricant
- MB
- Modello
- MB HLC/WSL 130/02
- Année
- 2001
- Application
- Lamination + coating
- Type of lamination/coating
- MULTIPLE COATINGS
- Working width (mm)
- 1215
- Materials
- BOPP, PETP, LDPE, LLDPE, PAPER & LAMINATES, ALU
- Speed
- 300 mpm
- First unwinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder
- 1000
- Secondary unwinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder
- 1000
- Third unwinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel unwinder
- 1000
- Rewinder type
- SINGLE POSITION SHAFTLESS
- Max diameter reel rewinder
- 1000
- Coating unit
- Interchangeable Trolley , Gravure Trolley and Wax/Hot melt trolley
- Second Coating unitr
- Interchangeable Trolley Solventless trolley , Gravure Trolley
- Drying
- 1st coating unit : 4 zones drier with 4 tunnel 2,5 m length each. Tot 10 m , thermo oil heat exchanger 2nd coating unit : vertical hood total length 3 mt
- Register controll
- Yes
- pumping mixing unit
- yes for solventless year 2018
- Corona treatment
- Yes Martignoni
- Note
- Wax Lamination, wax lamination with lacquering, wax coating one side / two side, hot melt full coat / registered, cold seal, wet / dry lamination, Registered lamination, coding . Totally 4 trolleys supplied : 1 gravure, 1 gravure for cold seal, solventless, hot melt Premelting pumping unit for hot melt 2 heating units for solentless trolley CO2 fire fighting system
| Code Machine | LA452 |
| Fabricant | MB |
| Modello | MB HLC/WSL 130/02 |
| Année | 2001 |
| Application | Lamination + coating |
| Type of lamination/coating | MULTIPLE COATINGS |
| Working width (mm) | 1215 |
| Materials | BOPP, PETP, LDPE, LLDPE, PAPER & LAMINATES, ALU |
| Speed | 300 mpm |
| First unwinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel unwinder | 1000 |
| Secondary unwinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel unwinder | 1000 |
| Third unwinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel unwinder | 1000 |
| Rewinder type | SINGLE POSITION SHAFTLESS |
| Max diameter reel rewinder | 1000 |
| Coating unit | Interchangeable Trolley , Gravure Trolley and Wax/Hot melt trolley |
| Second Coating unitr | Interchangeable Trolley Solventless trolley , Gravure Trolley |
| Drying | 1st coating unit : 4 zones drier with 4 tunnel 2,5 m length each. Tot 10 m , thermo oil heat exchanger 2nd coating unit : vertical hood total length 3 mt |
| Register controll | Yes |
| pumping mixing unit | yes for solventless year 2018 |
| Corona treatment | Yes Martignoni |
| Note | Wax Lamination, wax lamination with lacquering, wax coating one side / two side, hot melt full coat / registered, cold seal, wet / dry lamination, Registered lamination, coding . Totally 4 trolleys supplied : 1 gravure, 1 gravure for cold seal, solventless, hot melt Premelting pumping unit for hot melt 2 heating units for solentless trolley CO2 fire fighting system |
