- Code Machine
- CA225
- Fabricant
- TECHNO COATING ENGINEERING
- Modello
- HI TECH CAST LINE
- Année
- 2000
- Number of layers
- 3
- Film structure
- ABC
- Material
- Stretch film LLDPE
- Film width (mm)
- 2000
- Speed (m/min)
- 600 m/min
- Output (Kg/h)
- 500/550 kg/h
- Extruder 1 Layer ref:
- A
- Screw diam 1
- 130 mm
- Extruder 2 Layer ref:
- B
- Screw diam 2
- 65 mm
- Extruder 3 Layer ref:
- C
- Screw diam 3
- 65 mm
- Chill roll unit
- with 2 cylinders 850 mm and 315 mm
- Rewinder max reel diameter (mm)
- 2000 mm
- Rewinder description
- Rewinder with electro-welded and machined structure
| Code Machine | CA225 |
| Fabricant | TECHNO COATING ENGINEERING |
| Modello | HI TECH CAST LINE |
| Année | 2000 |
| Number of layers | 3 |
| Film structure | ABC |
| Material | Stretch film LLDPE |
| Film width (mm) | 2000 |
| Speed (m/min) | 600 m/min |
| Output (Kg/h) | 500/550 kg/h |
| Extruder 1 Layer ref: | A |
| Screw diam 1 | 130 mm |
| Extruder 2 Layer ref: | B |
| Screw diam 2 | 65 mm |
| Extruder 3 Layer ref: | C |
| Screw diam 3 | 65 mm |
| Chill roll unit | with 2 cylinders 850 mm and 315 mm |
| Rewinder max reel diameter (mm) | 2000 mm |
| Rewinder description | Rewinder with electro-welded and machined structure |
