- Code Machine
- RO117
- Fabricant
- CERUTTI
- Modello
- 48 R
- Année
- 1988
- Number of colors
- 9
- Web width (mm)
- 1390
- Print width (mm)
- 1320
- Print repeat range (mm)
- 450-1000 mm
- Drying specifications
- one drier c.m./h 10000 print station from 1 at 6 - drier length 2600mm ; double drier c.m./h 15800 for print station 7 -8 - drier length 4500mm.
- Drying heat surce
- from 1 to 6 print station with steam – from printing station 7-8 with gas heaters
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Videocamera
- Grafikontrol
- Register controll
- Crosfield
- Vyscosity control
- Crosfield
- Corona treatment
- No
- Print cylinders
- 80
- Note
- Print speed: 350/400 mt/min. On station 9th solvent laminating unit solventless Nordmeccanica.Preconditioning unit on unwinder.Gravure cylinders: Nr. 80 (available on option up to 200 cylinders). Cylinders shaft: Nr. 37 in two sizes 1070 and 1390 mm.Pressure rollers: 60 in different sizes.4 air shafts 70 mm + 6 air shafts ; 76 mm + 6 air shafts ;152 mm. No. 12 ink pumps, 15 ink trays + splashguards for 3 sizes
| Code Machine | RO117 |
| Fabricant | CERUTTI |
| Modello | 48 R |
| Année | 1988 |
| Number of colors | 9 |
| Web width (mm) | 1390 |
| Print width (mm) | 1320 |
| Print repeat range (mm) | 450-1000 mm |
| Drying specifications | one drier c.m./h 10000 print station from 1 at 6 - drier length 2600mm ; double drier c.m./h 15800 for print station 7 -8 - drier length 4500mm. |
| Drying heat surce | from 1 to 6 print station with steam – from printing station 7-8 with gas heaters |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Videocamera | Grafikontrol |
| Register controll | Crosfield |
| Vyscosity control | Crosfield |
| Corona treatment | No |
| Print cylinders | 80 |
| Note | Print speed: 350/400 mt/min. On station 9th solvent laminating unit solventless Nordmeccanica.Preconditioning unit on unwinder.Gravure cylinders: Nr. 80 (available on option up to 200 cylinders). Cylinders shaft: Nr. 37 in two sizes 1070 and 1390 mm.Pressure rollers: 60 in different sizes.4 air shafts 70 mm + 6 air shafts ; 76 mm + 6 air shafts ;152 mm. No. 12 ink pumps, 15 ink trays + splashguards for 3 sizes |
