ROTOMEC 3003-R-ES Imprimeus Helio 9 couleurs

Code Machine
RO234
Fabricant
ROTOMEC
Modello
3003-R-ES
Année
2000
Number of colors
9
Print possibilities
9+0 , 8+1
Drive
Electronic shaft
Trolley system
Yes
Web width (mm)
1030
Print width (mm)
1000
Print repeat range (mm)
450-860mm
Drying specifications
UNITS 1-8 Single drier one blowing fan each unit one general exhaust fan, Units 9-10 double hood two bloaing fans , one exhaust each unit
Drying heat surce
One main gas burner 1.500.000 kcal- totally 13 dying zones and temperature controls
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
1000
Videocamera
YES ELTROMAT
Register controll
Automatic Color Registor (Eltromat DGC650)
Vyscosity control
Yes Fasnacht
Corona treatment
yes
Note
totally 20 trolleys
Code Machine RO234
Fabricant ROTOMEC
Modello 3003-R-ES
Année 2000
Number of colors 9
Print possibilities 9+0 , 8+1
Drive Electronic shaft
Trolley system Yes
Web width (mm) 1030
Print width (mm) 1000
Print repeat range (mm) 450-860mm
Drying specifications UNITS 1-8 Single drier one blowing fan each unit one general exhaust fan, Units 9-10 double hood two bloaing fans , one exhaust each unit
Drying heat surce One main gas burner 1.500.000 kcal- totally 13 dying zones and temperature controls
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Videocamera YES ELTROMAT
Register controll Automatic Color Registor (Eltromat DGC650)
Vyscosity control Yes Fasnacht
Corona treatment yes
Note totally 20 trolleys
